Wharfedale Diamond 12.1 vs ELAC BS U5

Last updated: October 31, 2026

Short answer: the Wharfedale Diamond 12.1, since the ELAC BS U5 distorts badly at both crossovers. The BS U5’s three-way coaxial design is even on axis to 3kHz with off-axis behavior smoother still, but distortion is very high around 270Hz and 2700Hz at both 86 and 96dB SPL/1m, exceeding 3% at the mid-range crossover. The Diamond 12.1 keeps distortion under 1% THD to about 60Hz, though a 3dB dip in the crossover region saps attack.

Wharfedale Diamond 12.1 vs ELAC BS U5

Buy the Wharfedale Diamond 12.1 only if you find one used in good condition; both are discontinued, and it is the better rated of the two. For a new speaker, buy the Wharfedale Diamond 12.1i, which replaces the Wharfedale Diamond 12.1.

Want more options? Browse the full Passive Home rankings.

Measured Differences

Prices on this page were last checked November 14, 2026 at 6:17 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.

As an eBay Partner, we may be compensated if you make a purchase.

Specifications Side By Side

Wharfedale Diamond 12.1 ELAC BS U5
Price$599 per pair Discontinued$856 per pair Discontinued
Ranked#32 of 179 in Medium Size Bookshelf Speakers#118 of 179 in Medium Size Bookshelf Speakers
Bass Extension (-10dB)46Hz (measured, Erin’s Audio Corner)41Hz (derived, log-interpolated between spinorama.org -9dB/-12dB points)
Bass Extension (-3dB)61Hz (measured, Erin’s Audio Corner)63Hz (measured, Audio Science Review)
Crossover Frequency2.6kHz-
Dimensions12.2”H x 7”W x 10.9”D (310 x 178 x 277 mm)13.4”H x 7”W x 11.5”D (339.1 x 178.0 x 293.1 mm)
Impedance8 ohms nominal (3.9 ohms minimum above 80Hz, measured, Erin’s Audio Corner)4 ohms nominal (3.4 ohms minimum)
Sensitivity84dB (measured by Erin’s Audio Corner; 87dB manufacturer specified)83dB (2.83V/1m, measured, Audio Science Review)
Drivers5” advanced polypropylene cone woofer, 1” textile dome tweeter1” tweeter + 5.25” woofer
Weight15 lbs (6.8 kg) each13.2 lbs (6 kg)
Woofer Cabinetportedported, rear
Spinorama Preference Score5.014.71 (spinorama.org)
Spinorama Preference Score with Perfect Sub7.426.79 (spinorama.org)
DIY KitNoNo

Where the Ratings Come From

This comparison is generated from the ratings, specifications and measurements on each product’s own page, and it updates when that data changes. How we rank explains how each rating is decided.
