Short answer: the Revel M126Be for better sound quality, the JBL HDI-1600 for the lower price. The Revel M126Be ranks #28 of 100 bookshelf speakers at $4400. The JBL HDI-1600 ranks #35 at $1980, $2420 cheaper.
On the Revel M126Be side: Two-way design pairing a 6.5” midwoofer with a 1” beryllium dome tweeter, the smaller sibling to the reviewer’s favorite Revel F226Be. Set against that: At $4,400/pair, the reviewer doesn’t consider it a strong value - an improvement over Revel’s less expensive M106 and Performa3 models, but not proportional to the price jump.
The case for the JBL HDI-1600: CEA2034 spinorama is very flat in the critical mid-to-upper frequencies, with a slight bass boost that should have a good subjective effect and very smooth early-window directivity. The tradeoff: A dip appears above 10kHz on-axis.
Buy the Revel M126Be if sound quality matters more than the price. Buy the JBL HDI-1600 if the price matters more than sound quality.
Specifications Side By Side
| Revel M126Be | JBL HDI-1600 | |
|---|---|---|
| Price | $4400 | $1980 Discontinued |
| Ranked | #28 of 100 in Large Size Bookshelf Speakers | #35 of 100 in Large Size Bookshelf Speakers |
| Bass Extension (-10dB) | 44Hz (measured, Erin’s Audio Corner) | 55Hz (measured, Audio Science Review) |
| Bass Extension (-3dB) | 103Hz (measured, Erin’s Audio Corner) | 70Hz (measured, Audio Science Review) |
| Dimensions | 15.2"H x 8.3"W x 10.3"D (386.1 x 210.8 x 261.6 mm) | 14.6"H x 9.1"W x 11.4"D (370.0 x 230.0 x 288.9 mm) |
| Impedance | 6 ohms nominal (4.9 ohms minimum, measured, Erin’s Audio Corner) | 4 ohms nominal (measured, Audio Science Review) |
| Sensitivity | 86.1dB (measured, Erin’s Audio Corner) | 85dB (2.83V/1m, measured, Audio Science Review) |
| Drivers | 6.5" Deep Ceramic Composite (DCC) Aluminum Cone with cast frame woofer, 1" Beryllium dome with acoustic lens waveguide tweeter | 1" tweeter + 6.5" woofer |
| Weight | 22 lbs / 10.0 kg each | 53.4 lbs / 24.2 kg |
| Woofer Cabinet | ported, rear | ported, rear |
| Discontinued | - | Yes |
Related Speaker Comparisons
More useful head-to-heads from the same speaker class:
- Selah Audio Purezza vs ELAC VELA BS 403
- ELAC VELA BS 403 vs Buchardt S400 MKII
- ELAC VELA BS 403 vs Philharmonic BMR (v1)
- Revel M126Be vs JTR Noesis 210HT
- Wharfedale Linton 85 vs Revel M126Be
The Two Speakers In Full
Revel M126Be: $4400 Crutchfield
Pros: Two-way design pairing a 6.5” midwoofer with a 1” beryllium dome tweeter, the smaller sibling to the reviewer’s favorite Revel F226Be. Wide, immersive stereo imaging - hard-panned sounds in test tracks localized 2-3 feet outside the physical speaker positions without losing pinpoint precision. Horizontal radiation of about 60-70°, landing right in the reviewer’s preferred range for an enveloping yet still well-focused soundstage. Extended bass-shelf tuning (similar in concept to the KEF R3 Meta) combines with in-room gain for a more linear low end rather than a boomy hump. Diffraction dips visible on-axis around 3kHz and 7kHz largely disappear in the estimated in-room response, since they fill in as you move off-axis. Distortion stays within 3% down to about 100Hz at both 86dB and 96dB output - strong performance for a 6.5” bookshelf woofer. Can be driven by a standard AVR thanks to a manageable 4.9-ohm minimum impedance.
Cons: At $4,400/pair, the reviewer doesn’t consider it a strong value - an improvement over Revel’s less expensive M106 and Performa3 models, but not proportional to the price jump. Bass tops out around 50Hz in-room; a subwoofer is still needed for real low-end extension. Vertical placement is fairly critical - there’s a notable hole in the response around the 1.7kHz crossover if you sit above the tweeter axis. Toeing the speaker out to a full 30° introduces a roughly 1dB discontinuity in the midrange along with high-frequency rolloff; the reviewer recommends staying close to on-axis or within about 10°. An unexplained jump in distortion appears right at the 1.7kHz crossover point under compression testing, which may be linked to an occasional “glaring” quality the reviewer noticed in the 2-3kHz region at very high volumes (92-93dB from 2 meters). A mild 2-3kHz forwardness occasionally stood out on some tracks, correctable with about 1dB of EQ, though the reviewer considers it minor.
Full Revel M126Be review and specifications →
| Bass Extension (-10dB) | 44Hz (measured, Erin's Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 103Hz (measured, Erin's Audio Corner) |
| Dimensions | 15.2"H x 8.3"W x 10.3"D (386.1 x 210.8 x 261.6 mm) |
| Drivers | 6.5" Deep Ceramic Composite (DCC) Aluminum Cone with cast frame woofer, 1" Beryllium dome with acoustic lens waveguide tweeter |
| Impedance | 6 ohms nominal (4.9 ohms minimum, measured, Erin's Audio Corner) |
| Sensitivity | 86.1dB (measured, Erin's Audio Corner) |
| Weight | 22 lbs / 10.0 kg each |
| Woofer Cabinet | ported, rear |
As an eBay Partner, we may be compensated if you make a purchase.
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
- Revel M126Be vs ELAC VELA BS 403
- Revel M126Be vs Wharfedale Linton 85
- Revel M126Be vs Selah Audio Purezza
- Revel M126Be vs Emotiva Airmotiv XB2
- Revel M126Be vs Dynaudio Heritage Special
- Revel M126Be vs ELAC DB63
- Revel M126Be vs Radiant Acoustics Clarity 6.2
- Revel M126Be vs Wharfedale Super Linton
- See all 10 comparisons
JBL HDI-1600: $1980 Discontinued Crutchfield
Pros: CEA2034 spinorama is very flat in the critical mid-to-upper frequencies, with a slight bass boost that should have a good subjective effect and very smooth early-window directivity. Predicted in-room response in a simulated average listening room closely tracks the reviewer’s own preferred target curve.
Cons: A dip appears above 10kHz on-axis. Cumulative spectral decay (waterfall) shows some messiness around the crossover along with a 700Hz resonance. Harmonic distortion rises to nearly 2% right at the 1.9kHz crossover point at 96dB SPL/1m. Discontinued.
Full JBL HDI-1600 review and specifications →
| Bass Extension (-10dB) | 55Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 70Hz (measured, Audio Science Review) |
| Dimensions | 14.6"H x 9.1"W x 11.4"D (370.0 x 230.0 x 288.9 mm) |
| Discontinued | Yes |
| Drivers | 1" tweeter + 6.5" woofer |
| Impedance | 4 ohms nominal (measured, Audio Science Review) |
| Sensitivity | 85dB (2.83V/1m, measured, Audio Science Review) |
| Weight | 53.4 lbs / 24.2 kg |
| Woofer Cabinet | ported, rear |
