Short answer: the Revel F228Be for linearity, the PSB Imagine T65 for bass. The PSB’s dual 6.5” woven carbon fiber woofers give genuinely strong, extended low end, among the better performers in this price class, but a midrange/crossover dip muddies dialogue and vocal clarity. The F228Be is essentially flat on-axis with very nice directivity, held back by a 3.4-ohm minimum impedance and a secondary rise around 2kHz.
Buy the Revel F228Be when sound quality outweighs the price for you, and the PSB Imagine T65 when the price outweighs sound quality instead.
Want more options? Browse the full Passive Home rankings.
Specifications Side By Side
| Revel F228Be | PSB Imagine T65 | |
|---|---|---|
| Price | $9,000 per pair | $2,699 per pair |
| Ranked | #17 of 74 in Large Size Floorstanding Speakers | #34 of 74 in Large Size Floorstanding Speakers |
| Bass Extension (-10dB) | 25Hz (measured, Audio Science Review) | 26Hz (measured average, Erin’s Audio Corner) |
| Bass Extension (-3dB) | 61Hz (measured, Audio Science Review) | 47Hz (measured average, Erin’s Audio Corner) |
| Dimensions | 50.9”H x 13.5”W x 17.6”D (1292.9 x 342.9 x 447 mm) | 38.8” x 8.4” x 13.5” (986 x 213 x 343 mm) |
| Impedance | 8 ohms | 8 ohms nominal (3.3 ohms minimum measured by Erin’s Audio Corner; manufacturer specifies 4 ohms minimum) |
| Drivers | Dual 8” (200mm) Deep Ceramic Composite aluminum cones, with cast frames woofers, 5-1/4” (130mm) Deep Ceramic Composite aluminum cone, with cast frame midrange, 1” (25mm) Beryllium dome, with acoustic lens waveguide tweeter | 1” titanium dome tweeter, 5.25” woven carbon fiber midrange, 2x 6.5” woven carbon fiber woofers |
| Sensitivity | 89.3dB (300Hz-3kHz @ 2.83V/1m, measured by Audio Science Review; 90dB manufacturer specified) | 85.1dB (measured average, Erin’s Audio Corner) |
| Weight | 112.4 lbs (51 kg) each | 44.1 lbs (20 kg) each |
| Woofer Cabinet | ported, front | - |
| Spinorama Preference Score | 6.01 | 5.29 |
| Spinorama Preference Score with Perfect Sub | 7.51 | 6.51 |
| DIY Kit | No | No |
| Crossover Frequency | - | 600Hz & 2000Hz, 4th-order Linkwitz-Riley |
| Recommended Power | - | 20-200W |
| Enclosure | - | Vented: dual rear slot ports, individual woofer chambers |
| Frequency Response | - | 28Hz - 20kHz (±1.5dB, manufacturer specified) |
Related Speaker Comparisons
More top alternatives to Revel F228Be:
- KEF Blade Two Meta vs Revel F228Be
- MoFi SourcePoint V10 Master Edition vs Revel F228Be
- MoFi SourcePoint 888 vs Revel F228Be
- Revel F228Be vs Revel F328Be
- Radiant Acoustics Clarity 66 vs Revel F228Be
Prices on this page were last checked October 3, 2026 at 10:26 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
Revel F228Be: $9,000 per pair Crutchfield eBay
Older model: the Revel F208 (ranked higher, rated 4.5/5).
Pros: CEA2034 spinorama shows an essentially flat on-axis response with very nice directivity. Predicted in-room response is nearly perfect, with a smooth slope down from bass to treble. Horizontal beamwidth of about ±70 degrees is wide and holds up well until narrowing above 8kHz. Vertical directivity offers more degrees of listening-height freedom than a typical bookshelf design, a benefit of this tower’s driver layout. Distortion is extremely low across the full audio range at 86dB SPL/1m and stays comfortable even at 96dB SPL/1m. Near-field measurements of the individual drivers show nice, well-integrated crossover behavior with only low-level resonances. Measured bass extension of 61Hz (-3dB), with a measured sensitivity of 89.3dB.
Cons: Minimum impedance dips to 3.4 ohms with a secondary rise around 2kHz, calling for an amplifier comfortable with a demanding load. Very expensive and very heavy (51 kg each).
Full Revel F228Be review and specifications →
| Bass Extension (-10dB) | 25Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 61Hz (measured, Audio Science Review) |
| DIY Kit | No |
| Dimensions | 50.9”H x 13.5”W x 17.6”D (1292.9 x 342.9 x 447 mm) |
| Drivers | Dual 8” (200mm) Deep Ceramic Composite aluminum cones, with cast frames woofers, 5-1/4” (130mm) Deep Ceramic Composite aluminum cone, with cast frame midrange, 1” (25mm) Beryllium dome, with acoustic lens waveguide tweeter |
| Impedance | 8 ohms |
| Sensitivity | 89.3dB (300Hz-3kHz @ 2.83V/1m, measured by Audio Science Review; 90dB manufacturer specified) |
| Spinorama Preference Score | 6.01 |
| Spinorama Preference Score with Perfect Sub | 7.51 |
| Weight | 112.4 lbs (51 kg) each |
| Woofer Cabinet | ported, front |
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
PSB Imagine T65: $2,699 per pair PSB Speakers eBay
Pros: Three-way design with dual 6.5” woven carbon fiber woofers delivers genuinely strong, extended low end for a $2699 tower: among the better performers Erin has measured in this price class. Distortion shows a clean second-order character with clear separation from third-order all the way up to 96 dB, indicating a well-controlled motor. Compression data shows enhancement rather than compression below about 50-60 Hz, so the bass can sound louder as you turn it up rather than choking off. Wide, forgiving vertical listening window (about ±25°) thanks to the 3-way layout, giving more seating and placement flexibility than most towers. Plenty of dynamic headroom for home theater use or a two-channel system: 100W drove it comfortably in Erin’s room. Measured bass extension of 47Hz (-3dB), with a measured sensitivity of 85.1dB.
Cons: Noticeable dip in the midrange/crossover region that Erin flagged as affecting dialogue and vocal clarity, though he notes a couple bands of EQ smooths it out. Some horizontal dispersion mismatch (about 10-15° of ballooning between 1-3 kHz) between the midrange and tweeter can add extra perceived attack or detail if your room’s sidewalls are reflective. Dips to 4 ohms, so it wants an amplifier comfortable driving a 4-ohm load. Distortion climbs above 3% around 60 Hz at 96 dB, though it’s benign second-order distortion.
Full PSB Imagine T65 review and specifications →
| Bass Extension (-10dB) | 26Hz (measured average, Erin’s Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 47Hz (measured average, Erin’s Audio Corner) |
| Crossover Frequency | 600Hz & 2000Hz, 4th-order Linkwitz-Riley |
| DIY Kit | No |
| Dimensions | 38.8” x 8.4” x 13.5” (986 x 213 x 343 mm) |
| Drivers | 1” titanium dome tweeter, 5.25” woven carbon fiber midrange, 2x 6.5” woven carbon fiber woofers |
| Enclosure | Vented: dual rear slot ports, individual woofer chambers |
| Frequency Response | 28Hz - 20kHz (±1.5dB, manufacturer specified) |
| Impedance | 8 ohms nominal (3.3 ohms minimum measured by Erin’s Audio Corner; manufacturer specifies 4 ohms minimum) |
| Recommended Power | 20-200W |
| Sensitivity | 85.1dB (measured average, Erin’s Audio Corner) |
| Spinorama Preference Score | 5.29 |
| Spinorama Preference Score with Perfect Sub | 6.51 |
| Weight | 44.1 lbs (20 kg) each |
