Revel F228Be vs JBL HDI-3600

Last updated: October 21, 2026

Short answer: the Revel F228Be for directivity, the JBL HDI-3600 for efficiency. The JBL combines a flat overall response and very low midrange distortion with high 90dB sensitivity, but a wide shelving-down above 2kHz affects the in-room response and its vertical dispersion dip is wider than the HDI-1600’s, making it more audible. The F228Be is essentially flat on-axis with very nice directivity, though it dips to 3.4 ohms.

Revel F228Be vs JBL HDI-3600

Buy the Revel F228Be if sound quality is the priority over the price, or the JBL HDI-3600 if the price is the priority over sound quality.

Looking for alternatives? See the complete Passive Home rankings.

Measured Differences

Prices on this page were last checked November 14, 2026 at 6:17 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.

As an eBay Partner, we may be compensated if you make a purchase.

Specifications Side By Side

Revel F228Be JBL HDI-3600
Price$11,000 per pair$3800 per pair
Ranked#29 of 228 in Large Size Floorstanding Speakers#63 of 228 in Large Size Floorstanding Speakers
Bass Extension (-10dB)25Hz (measured, Audio Science Review)62Hz - the on-axis curve also shows an unusual step/dip around 40-55Hz that may be a near-field-scan artifact for this tower (measured, Audio Science Review)
Bass Extension (-3dB)61Hz (measured, Audio Science Review)78Hz - the on-axis curve also shows an unusual step/dip around 40-55Hz that may be a near-field-scan artifact for this tower (measured, Audio Science Review)
Dimensions50.9”H x 13.5”W x 17.6”D (1292.9 x 342.9 x 447 mm)40.5”H x 10.2”W x 13.5”D (1029 x 260 x 343 mm)
Impedance8 ohms4 ohms nominal
DriversDual 8” (200mm) Deep Ceramic Composite aluminum cones, with cast frames woofers, 5-1/4” (130mm) Deep Ceramic Composite aluminum cone, with cast frame midrange, 1” (25mm) Beryllium dome, with acoustic lens waveguide tweeter2410H-2 1” compression driver, 3x 6.5” Advanced Aluminum Matrix woofers
Sensitivity89.3dB (300Hz-3kHz @ 2.83V/1m, measured by Audio Science Review; 90dB manufacturer specified)89.5dB (2.83V/1m, measured, Audio Science Review)
Weight112.4 lbs (51 kg) each61.7 lbs (28 kg) each
Woofer Cabinetported, frontported, dual rear-firing
Spinorama Preference Score6.014.64 (spinorama.org)
Spinorama Preference Score with Perfect Sub7.516.95 (spinorama.org)
DIY KitNoNo
Frequency Response-38Hz - 30kHz (+/-3dB) (Manufacturer specified)

Where the Ratings Come From

This comparison is generated from the ratings, specifications and measurements on each product’s own page, and it updates when that data changes. How we rank explains how each rating is decided.
