Q Acoustics 3020i vs Wharfedale Diamond 220

Last updated: October 31, 2026

Bottom line: both are discontinued, so this only matters if you are buying used. Used, the Wharfedale Diamond 220 is the better pick: it ranks #50 of 179 bookshelf speakers by sound quality (rated 3.7/5), against #146 (rated 2.4/5) for the Q Acoustics 3020i. If you want one new, the Wharfedale Diamond 12.1i replaces the Wharfedale Diamond 220 and is rated 4.0/5 at $499.

Q Acoustics 3020i vs Wharfedale Diamond 220

The Q Acoustics 3020i is the deeper-bass pick. An attractive discontinued bookshelf speaker with recessed binding posts that improves substantially with EQ. Its bass reaches about 82Hz before falling 3dB, against 117.2Hz for the Wharfedale Diamond 220. Keep in mind: On-axis response shows a rising upper-frequency trend and a dip in the 2-4kHz crossover region alongside two resonance-related dips; a significant resonance appears at 366Hz in the waterfall plot.

The Wharfedale Diamond 220 is the better-sounding option. Budget bookshelf speakers with a waveguide tweeter, wide dispersion and controlled distortion, best heard with the grille off. The downside: Response rolls off below 200Hz, so a subwoofer is recommended for full-range use.

Buy the Wharfedale Diamond 220 only if you find one used in good condition; both are discontinued, and it is the better rated of the two. For a new speaker, buy the Wharfedale Diamond 12.1i, which replaces the Wharfedale Diamond 220.

Still deciding? The full Passive Home rankings cover every ranked option.

Measured Differences

Prices on this page were last checked November 18, 2026 at 8:41 AM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.

As an eBay Partner, we may be compensated if you make a purchase.

Specifications Side By Side

Q Acoustics 3020i Wharfedale Diamond 220
Price$314.99 per pair Discontinued$299 per pair Discontinued
Ranked#146 of 179 in Medium Size Bookshelf Speakers#50 of 179 in Medium Size Bookshelf Speakers
Drivers125mm (5”) bass driver, 22mm (0.9”) tweeter5” (130mm) woven Kevlar woofer, 1” (25mm) tweeter
Dimensions10.9”H x 6.7”W x 11.1”D (278 x 170 x 282 mm)12.4”H x 6.9”W x 8.9”D (315 x 174 x 227 mm)
Weight10.6 lbs (4.8 kg) each11.7 lbs (5.3 kg) each
Sensitivity86dB (2.83V/1m, manufacturer specified)86.9dB (2.83V/1m, measured, Audio Science Review; 86dB manufacturer specified)
Crossover Frequency2.4kHz-
Impedance6 ohms nominal, 4 ohms minimum8 ohms
Woofer Cabinetported, reflexported, bottom-firing into secondary enclosure
Bass Extension (-3dB)82.0Hz (measured, Audio Science Review)117.2Hz (measured, Audio Science Review)
Bass Extension (-10dB)49.8Hz (measured, Audio Science Review)58.0Hz (measured, Audio Science Review)
Spinorama Preference Score3.863.40
Spinorama Preference Score with Perfect Sub6.386.64
DIY KitNoNo

Where the Ratings Come From

This comparison is generated from the ratings, specifications and measurements on each product’s own page, and it updates when that data changes. How we rank explains how each rating is decided.
