Short answer: the Revel M105, unless you want a grille-off budget speaker. Amir found the Diamond 220’s on-axis response smooth once the grille is removed, calling grille removal a huge improvement because the stock grille caused unusually strong comb filtering around 5kHz, and its response rolls off below 200Hz, so a subwoofer is recommended. The M105 is essentially flat on-axis with a smooth listening window and clean decay.
Buy the Revel M105 only if you find one used in good condition; both are discontinued, and it is the better rated of the two. For a new speaker, start with the Philharmonic Ceramic Mini instead.
Want more options? Browse the full Passive Home rankings.
Specifications Side By Side
| Revel M105 | Wharfedale Diamond 220 | |
|---|---|---|
| Price | $1,500 per pair Discontinued | $299 per pair Discontinued |
| Ranked | #13 of 90 in Medium Size Bookshelf Speakers | #28 of 90 in Medium Size Bookshelf Speakers |
| Bass Extension (-3dB) | 63Hz (measured, Audio Science Review) | 117.2Hz (measured, Audio Science Review) |
| Bass Extension (-10dB) | 49.8Hz (derived, log-interpolated between spinorama.org -9dB/-12dB points) | 58.0Hz (measured, Audio Science Review) |
| Sensitivity | 85dB (2.83V/1m, measured, Audio Science Review) | 86.9dB (2.83V/1m, measured, Audio Science Review; 86dB manufacturer specified) |
| Impedance | 8 ohms nominal, low minimum | 8 ohms |
| Frequency Response | 60Hz - 44kHz (+/-3dB) (Manufacturer specified) | - |
| Drivers | 5.25” aluminum cone woofer, 1” aluminum tweeter with acoustic lens waveguide | 5” (130mm) woven Kevlar woofer, 1” (25mm) tweeter |
| Weight | 15.4 lbs (7 kg) each | 11.7 lbs (5.3 kg) each |
| Dimensions | 14”H x 7.9”W x 9.8”D (355.6 x 200.7 x 248.9 mm) | 12.4”H x 6.9”W x 8.9”D (315 x 174 x 227 mm) |
| Woofer Cabinet | ported, rear | ported, bottom-firing into secondary enclosure |
| Spinorama Preference Score | 5.76 | 3.40 |
| Spinorama Preference Score with Perfect Sub | 8.18 | 6.64 |
| DIY Kit | No | No |
Related Speaker Comparisons
More top alternatives to Revel M105:
- Ascend Sierra 1 v2 vs Revel M105
- KEF LS50 Meta vs Revel M105
- Arendal 1961 Monitor vs Revel M105
- Monitor Audio Silver 50 7G vs Revel M105
- Revel M105 vs Klipsch RP-500M II
Prices on this page were last checked October 2, 2026 at 10:18 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
Revel M105: $1,500 per pair Discontinued eBay
Pros: CEA2034 spinorama shows an essentially flat on-axis response with only a small 5kHz peak, a smooth listening window, and clean waterfall decay. Wide horizontal dispersion gives flexibility with toe-in. The reviewer called it reference-quality performance with minor EQ correction applied. Measured bass extension of 63Hz (-3dB), with a measured sensitivity of 85dB.
Cons: Low nominal impedance demands a capable amplifier that can handle low-impedance loads. Bass distortion runs high in the 80-250Hz range from woofer displacement, and maximum output is limited compared to larger designs. Discontinued.
Full Revel M105 review and specifications →
| Bass Extension (-10dB) | 49.8Hz (derived, log-interpolated between spinorama.org -9dB/-12dB points) |
|---|---|
| Bass Extension (-3dB) | 63Hz (measured, Audio Science Review) |
| DIY Kit | No |
| Dimensions | 14”H x 7.9”W x 9.8”D (355.6 x 200.7 x 248.9 mm) |
| Drivers | 5.25” aluminum cone woofer, 1” aluminum tweeter with acoustic lens waveguide |
| Frequency Response | 60Hz - 44kHz (+/-3dB) (Manufacturer specified) |
| Impedance | 8 ohms nominal, low minimum |
| Sensitivity | 85dB (2.83V/1m, measured, Audio Science Review) |
| Spinorama Preference Score | 5.76 |
| Spinorama Preference Score with Perfect Sub | 8.18 |
| Weight | 15.4 lbs (7 kg) each |
| Woofer Cabinet | ported, rear |
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
Wharfedale Diamond 220: $299 per pair Discontinued eBay
Newer model: the Wharfedale Diamond 12.1i. It’s likely to perform similarly, though we don’t have measurements to confirm that yet.
Pros: Amir found the on-axis response smooth once the grille is removed, calling grille removal “a huge improvement” since the stock grille caused unusually strong comb filtering around 5kHz. Good horizontal dispersion from the waveguide-loaded tweeter and controlled distortion. After some EQ (a room mode filter and treble shelf), the reviewer called it “a truly hifi speaker” where “every audiophile track..sounded very good,” and said he was “happy to recommend” it for the budget class. Measured bass extension of 117.2Hz (-3dB), with a measured sensitivity of 86.9dB.
Cons: Response rolls off below 200Hz, so a subwoofer is recommended for full-range use. Some port rattling was noted at high volumes, traced to vibration rather than the woofer itself. Best performance requires removing the grille and applying the reviewer’s EQ filters. Discontinued, with only limited remaining stock available direct from Wharfedale.
Full Wharfedale Diamond 220 review and specifications →
| Bass Extension (-10dB) | 58.0Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 117.2Hz (measured, Audio Science Review) |
| DIY Kit | No |
| Dimensions | 12.4”H x 6.9”W x 8.9”D (315 x 174 x 227 mm) |
| Drivers | 5” (130mm) woven Kevlar woofer, 1” (25mm) tweeter |
| Impedance | 8 ohms |
| Sensitivity | 86.9dB (2.83V/1m, measured, Audio Science Review; 86dB manufacturer specified) |
| Spinorama Preference Score | 3.40 |
| Spinorama Preference Score with Perfect Sub | 6.64 |
| Weight | 11.7 lbs (5.3 kg) each |
| Woofer Cabinet | ported, bottom-firing into secondary enclosure |
