Short answer: both are discontinued, so this only matters if you are buying used, though neither ranks well in its class. Used, the Pioneer SP-BS22-LR (Philharmonic AAM Mod) is the better pick: it ranks #111 of 160 bookshelf speakers by sound quality (rated 2.8/5), against #152 (rated 1.6/5) for the Pioneer Elite SP-EBS73-LR. Both are rated below 3.0/5 among the 160 bookshelf speakers, so if sound quality matters, consider the Philharmonic Ceramic Mini instead, ranked #2 at $900.
The Pioneer SP-BS22-LR (Philharmonic AAM Mod) is the more accurate pick. This is Dennis Murphy’s “Affordable Accuracy Monitor” (AAM) mod of the discontinued, budget Pioneer SP-BS22-LR: the stock tweeter is swapped for a Peerless BC25TG15 dome and a redesigned 3rd-order crossover is built to match it to the stock 4” woofer. Its measured preference score, a predictor of how neutral it sounds, is 5.07 against 3.22 for the Pioneer Elite SP-EBS73-LR. Watch for: Some directivity error appears near the crossover frequency.
The Pioneer Elite SP-EBS73-LR is the deeper-bass choice. Unique dual-driver design combines a front-facing 3-way speaker with an up-firing 2-way Dolby Atmos coaxial driver in one cabinet, designed by Andrew Jones. Its bass reaches about 64.5Hz before falling 3dB, against 78Hz for the Pioneer SP-BS22-LR (Philharmonic AAM Mod). The catch: A wide dip between 3-10kHz makes the front speaker sound “somewhat dull” without EQ, and impedance dips below 4 ohms demand a capable amplifier.
Buy the Pioneer SP-BS22-LR (Philharmonic AAM Mod) only if you find one used in good condition; both are discontinued, and it is the better rated of the two. For a new speaker, start with the Philharmonic Ceramic Mini instead.
Want more options? Browse the full Passive Home rankings.
Specifications Side By Side
| Pioneer SP-BS22-LR (Philharmonic AAM Mod) | Pioneer Elite SP-EBS73-LR | |
|---|---|---|
| Price | $168 per pair Discontinued | $749 per pair Discontinued |
| Ranked | #111 of 160 in Medium Size Bookshelf Speakers | #152 of 160 in Medium Size Bookshelf Speakers |
| Bass Extension (-3dB) | 78Hz (measured, Audio Science Review) | 64.5Hz (measured, Audio Science Review) |
| Bass Extension (-10dB) | 60Hz (measured, Audio Science Review) | 45.9Hz (measured, Audio Science Review) |
| Drivers | 1x 4” curvilinear-cone woofer (stock Pioneer), 1x Peerless BC25TG15 1” silk dome tweeter (replacement) | 5.25” aluminum-cone woofer, 2x 4” aluminum-cone midrange, 2x 1” silk dome tweeter (front 3-way + up-firing 2-way Atmos coaxial) |
| Weight | 9 lbs (4.1 kg) | 15.7 lbs (7.1 kg) each |
| Sensitivity | 83dB (2.83V/1m, measured by Audio Science Review) | 85dB (manufacturer specified) |
| Impedance | 8 ohms nominal (approx. 5 ohms minimum, measured by Audio Science Review) | below 4 ohms minimum |
| Crossover Frequency | 3000Hz | - |
| Dimensions | 12.6”H x 7.1”W x 8.5”D (320.0 x 180.0 x 215.0 mm) | 15.7H x 7.4W x 9.7D in |
| Woofer Cabinet | ported, rear | - |
| Spinorama Preference Score | 5.07 | 3.22 |
| Spinorama Preference Score with Perfect Sub | 7.82 | 5.53 |
| DIY Kit | Yes | No |
Related Speaker Comparisons
More worthwhile head-to-heads for Pioneer SP-BS22-LR (Philharmonic AAM Mod):
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs Ascend Sierra 1 v2
- KEF LS50 Meta vs Pioneer SP-BS22-LR (Philharmonic AAM Mod)
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs Arendal 1961 Monitor
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs Revel M105
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs Klipsch RP-500M II
Prices on this page were last checked October 9, 2026 at 8:01 AM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
Pioneer SP-BS22-LR (Philharmonic AAM Mod): $168 per pair Discontinued eBay
Pros: This is Dennis Murphy’s “Affordable Accuracy Monitor” (AAM) mod of the discontinued, budget Pioneer SP-BS22-LR: the stock tweeter is swapped for a Peerless BC25TG15 dome and a redesigned 3rd-order crossover is built to match it to the stock 4” woofer. CEA2034 spinorama shows only small variations from a flat on-axis response with some directivity error near the crossover, a marked improvement over the unmodified Pioneer, which the reviewer notes shows much more variation from flat. Distortion at 86dB SPL/1m is reasonably controlled above 200Hz, and tweeter distortion barely rises even at 96dB SPL/1m. Measured bass extension of 78Hz (-3dB), with a measured sensitivity of 83dB.
Cons: Some directivity error appears near the crossover frequency. Distortion climbs in the woofer’s range (below 200Hz) at both 86dB and 96dB SPL/1m. Minimum impedance dips to about 5 ohms with a couple of resonance peaks. This is a DIY project, not a finished retail product: Murphy sold ~$168 pre-built pairs for a while but no longer does, so it now requires sourcing a used/discontinued Pioneer SP-BS22-LR pair plus building the crossover and swapping the tweeter yourself. The mod itself is public domain, but there is no current turnkey way to buy this speaker.
Full Pioneer SP-BS22-LR (Philharmonic AAM Mod) review and specifications →
| Bass Extension (-10dB) | 60Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 78Hz (measured, Audio Science Review) |
| Crossover Frequency | 3000Hz |
| DIY Kit | Yes |
| Dimensions | 12.6”H x 7.1”W x 8.5”D (320.0 x 180.0 x 215.0 mm) |
| Drivers | 1x 4” curvilinear-cone woofer (stock Pioneer), 1x Peerless BC25TG15 1” silk dome tweeter (replacement) |
| Impedance | 8 ohms nominal (approx. 5 ohms minimum, measured by Audio Science Review) |
| Sensitivity | 83dB (2.83V/1m, measured by Audio Science Review) |
| Spinorama Preference Score | 5.07 |
| Spinorama Preference Score with Perfect Sub | 7.82 |
| Weight | 9 lbs (4.1 kg) |
| Woofer Cabinet | ported, rear |
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs Dynaudio X14
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs MartinLogan Motion 4i
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs ELAC BS U5
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs JBL L52 Classic
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs Dynaudio Emit M10
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs Parts Express Copperhead Desktop Kit
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs JBL Stage A120
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs ELAC Uni-Fi 2.0 UB52
- See all 36 comparisons
Pioneer Elite SP-EBS73-LR: $749 per pair Discontinued eBay
Same family: the Pioneer Elite SP-EC73 (center, rated 3.3/5).
Pros: Unique dual-driver design combines a front-facing 3-way speaker with an up-firing 2-way Dolby Atmos coaxial driver in one cabinet, designed by Andrew Jones. With corrective EQ applied, the reviewer found “substantially more brilliance and detail,” and the up-firing Atmos driver produced “remarkable” spatial effects from a single box. Measured bass extension of 64.5Hz (-3dB).
Cons: A wide dip between 3-10kHz makes the front speaker sound “somewhat dull” without EQ, and impedance dips below 4 ohms demand a capable amplifier. Distortion is elevated at the crossover points, around 180Hz and 2600Hz. Amir concluded: “The hole in frequency response and high distortion around the crossover point rule out this speaker for any kind of hifi use, certainly at these prices.” Long discontinued.
Full Pioneer Elite SP-EBS73-LR review and specifications →
| Bass Extension (-10dB) | 45.9Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 64.5Hz (measured, Audio Science Review) |
| DIY Kit | No |
| Dimensions | 15.7H x 7.4W x 9.7D in |
| Drivers | 5.25” aluminum-cone woofer, 2x 4” aluminum-cone midrange, 2x 1” silk dome tweeter (front 3-way + up-firing 2-way Atmos coaxial) |
| Impedance | below 4 ohms minimum |
| Sensitivity | 85dB (manufacturer specified) |
| Spinorama Preference Score | 3.22 |
| Spinorama Preference Score with Perfect Sub | 5.53 |
| Weight | 15.7 lbs (7.1 kg) each |
