Short answer: the Pioneer SP-BS22-LR (Philharmonic AAM Mod) for better sound quality, the Klipsch R-41M for the lower price. The Pioneer SP-BS22-LR (Philharmonic AAM Mod) ranks #61 of 87 bookshelf speakers at $168. The Klipsch R-41M ranks #85 at $149, $19 cheaper.
What the Pioneer SP-BS22-LR (Philharmonic AAM Mod) offers: This is Dennis Murphy’s “Affordable Accuracy Monitor” (AAM) mod of the discontinued, budget Pioneer SP-BS22-LR: the stock tweeter is swapped for a Peerless BC25TG15 dome and a redesigned 3rd-order crossover is built to match it to the stock 4” woofer. CEA2034 spinorama shows only small variations from a flat on-axis response with some directivity error near the crossover, a marked improvement over the unmodified Pioneer, which the reviewer notes shows much more variation from flat. Distortion at 86dB SPL/1m is reasonably controlled above 200Hz, and tweeter distortion barely rises even at 96dB SPL/1m. Watch for: Some directivity error appears near the crossover frequency. Distortion climbs in the woofer’s range (below 200Hz) at both 86dB and 96dB SPL/1m. Minimum impedance dips to about 5 ohms with a couple of resonance peaks. This is a DIY project, not a finished retail product: Murphy sold ~$168 pre-built pairs for a while but no longer does, so it now requires sourcing a used/discontinued Pioneer SP-BS22-LR pair plus building the crossover and swapping the tweeter yourself. The mod itself is public domain, but there is no current turnkey way to buy this speaker.
What the Klipsch R-41M offers: Binding posts are unusually nice for the price point, and impedance is well controlled in the bass, easing the load on the amplifier. The horn-loaded tweeter can play loud without strain. Watch for: CEA2034 spinorama shows a sharp, prominent peak around 1kHz that the reviewer compared to “Pinocchio’s nose,” plus poor directivity that makes the off-axis sound diverge sharply from on-axis. Sensitivity is only 85dB through most of the music-energy range despite Klipsch’s horn-loaded reputation for efficiency. In an A/B against a $118/pair Pioneer SP-BS22-LR, the R-41M had “no bass” and all mid-to-treble energy; the reviewer’s verdict was “please avoid the Klipsch R-41M unless you just want a speaker as an ornament.”
Buy the Pioneer SP-BS22-LR (Philharmonic AAM Mod) if sound quality matters more than the price. Buy the Klipsch R-41M if the price matters more than sound quality.
If sound quality matters at all to you, skip the Klipsch R-41M. It ranks near the bottom of the 87 bookshelf speakers, so look higher up the list instead.
Specifications Side By Side
| Pioneer SP-BS22-LR (Philharmonic AAM Mod) | Klipsch R-41M | |
|---|---|---|
| Price | $168 | $149.00 |
| Ranked | #61 of 87 in Medium Size Bookshelf Speakers | #85 of 87 in Medium Size Bookshelf Speakers |
| Bass Extension (-3dB) | 78Hz (measured, Audio Science Review) | 80Hz (measured, Audio Science Review) |
| Bass Extension (-10dB) | 60Hz (measured, Audio Science Review) | 55Hz (measured, Audio Science Review) |
| Drivers | 1x 4" curvilinear-cone woofer (stock Pioneer), 1x Peerless BC25TG15 1" silk dome tweeter (replacement) | 4" spun-copper IMG woofer, 1" Tractrix horn-loaded aluminum dome tweeter |
| Weight | 9 lbs / 4.1 kg | 7 lbs / 3.18 kg each |
| Sensitivity | 83dB (2.83V/1m, measured by Audio Science Review) | 85dB (2.83V/1m, measured) |
| Impedance | 8 ohms nominal (approx. 5 ohms minimum, measured by Audio Science Review) | 8 ohms nominal (per spec; measured lower) |
| Crossover Frequency | 3000Hz | - |
| Dimensions | 12.6"H x 7.1"W x 8.5"D (320.0 x 180.0 x 215.0 mm) | 11.3H x 5.75W x 7.9D in |
| Woofer Cabinet | ported, rear | ported, rear |
| Frequency Response | - | 68Hz - 21kHz (Manufacturer specified) |
| Power Handling | - | 50W RMS / 200W peak |
Related Speaker Comparisons
More useful head-to-heads from the same speaker class:
- Parts Express Copperhead Desktop Kit vs Jamo S 803
- Jamo C 93 II vs Jamo S 803
- Neumi BS5 vs Jamo S 803
- JBL Control 1 Pro vs Klipsch R-41M
- Micca RB42 vs Klipsch R-41M
Prices on this page were last checked August 25, 2026 at 6:19 AM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
Pioneer SP-BS22-LR (Philharmonic AAM Mod): $168 eBay
Pros: This is Dennis Murphy’s “Affordable Accuracy Monitor” (AAM) mod of the discontinued, budget Pioneer SP-BS22-LR: the stock tweeter is swapped for a Peerless BC25TG15 dome and a redesigned 3rd-order crossover is built to match it to the stock 4” woofer. CEA2034 spinorama shows only small variations from a flat on-axis response with some directivity error near the crossover, a marked improvement over the unmodified Pioneer, which the reviewer notes shows much more variation from flat. Distortion at 86dB SPL/1m is reasonably controlled above 200Hz, and tweeter distortion barely rises even at 96dB SPL/1m.
Cons: Some directivity error appears near the crossover frequency. Distortion climbs in the woofer’s range (below 200Hz) at both 86dB and 96dB SPL/1m. Minimum impedance dips to about 5 ohms with a couple of resonance peaks. This is a DIY project, not a finished retail product: Murphy sold ~$168 pre-built pairs for a while but no longer does, so it now requires sourcing a used/discontinued Pioneer SP-BS22-LR pair plus building the crossover and swapping the tweeter yourself. The mod itself is public domain, but there is no current turnkey way to buy this speaker.
Full Pioneer SP-BS22-LR (Philharmonic AAM Mod) review and specifications →
| Bass Extension (-10dB) | 60Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 78Hz (measured, Audio Science Review) |
| Crossover Frequency | 3000Hz |
| Dimensions | 12.6"H x 7.1"W x 8.5"D (320.0 x 180.0 x 215.0 mm) |
| Drivers | 1x 4" curvilinear-cone woofer (stock Pioneer), 1x Peerless BC25TG15 1" silk dome tweeter (replacement) |
| Impedance | 8 ohms nominal (approx. 5 ohms minimum, measured by Audio Science Review) |
| Sensitivity | 83dB (2.83V/1m, measured by Audio Science Review) |
| Weight | 9 lbs / 4.1 kg |
| Woofer Cabinet | ported, rear |
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs Dynaudio X14
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs JBL L52 Classic
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs JBL Stage 2 250B
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs Parts Express Copperhead Desktop Kit
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs ELAC BS U5
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs JBL Stage A120
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs Dynaudio Emit M10
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs ELAC Uni-Fi 2.0 UB52
- See all 35 comparisons
Klipsch R-41M: $149.00 Amazon eBay
Pros: Binding posts are unusually nice for the price point, and impedance is well controlled in the bass, easing the load on the amplifier. The horn-loaded tweeter can play loud without strain.
Cons: CEA2034 spinorama shows a sharp, prominent peak around 1kHz that the reviewer compared to “Pinocchio’s nose,” plus poor directivity that makes the off-axis sound diverge sharply from on-axis. Sensitivity is only 85dB through most of the music-energy range despite Klipsch’s horn-loaded reputation for efficiency. In an A/B against a $118/pair Pioneer SP-BS22-LR, the R-41M had “no bass” and all mid-to-treble energy; the reviewer’s verdict was “please avoid the Klipsch R-41M unless you just want a speaker as an ornament.”
Full Klipsch R-41M review and specifications →
| Bass Extension (-10dB) | 55Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 80Hz (measured, Audio Science Review) |
| Dimensions | 11.3H x 5.75W x 7.9D in |
| Drivers | 4" spun-copper IMG woofer, 1" Tractrix horn-loaded aluminum dome tweeter |
| Frequency Response | 68Hz - 21kHz (Manufacturer specified) |
| Impedance | 8 ohms nominal (per spec; measured lower) |
| Power Handling | 50W RMS / 200W peak |
| Sensitivity | 85dB (2.83V/1m, measured) |
| Weight | 7 lbs / 3.18 kg each |
| Woofer Cabinet | ported, rear |
