Short answer: the Miller & Kreisel IW150. It ranks #13 of 18 in-wall speakers by sound quality, rated 3.6/5, at $4,998. The Revel W990 ranks #15, rated 3.5/5, at $4,239.90, $758.10 cheaper, not enough of a saving to outweigh the sound-quality gap.
The case for the Miller & Kreisel IW150: Erin’s Audio Corner’s Klippel measurement shows well controlled directivity (SPDI deviation 2.43dB) and a smooth predicted in-room response, with a preference score of 2.88, or 6.32 with a perfect subwoofer. The catch: Bass is thin: measured -3dB is 95.2Hz and -6dB is 82.0Hz, and Miller & Kreisel rates it only to 80Hz, so a subwoofer is required, and even with a perfect subwoofer the score reaches only 6.32.
Why pick the Revel W990: Audio Science Review’s Klippel measurement shows some of the deepest bass of any in-wall speaker, with -3dB at 32.2Hz and -6dB at 27.8Hz, so it can carry music without a subwoofer better than most. Watch for: Its measured preference score is only 3.6, or 5.09 with a perfect subwoofer, because the midrange is uneven: on-axis deviation is high (0.86 normalized deviation on axis, 0.69 in the listening window) and on-axis smoothness is just 0.34.
Buy the Miller & Kreisel IW150. It is rated higher for sound quality, and the $758.10 saving on the Revel W990 is not enough to make up the difference.
Want more options? Browse the full Passive Home rankings.
Specifications Side By Side
| Miller & Kreisel IW150 | Revel W990 | |
|---|---|---|
| Price | $4,998 per pair | $4,239.90 per pair |
| Ranked | #13 of 18 in In-Wall & In-Ceiling Speakers | #15 of 18 in In-Wall & In-Ceiling Speakers |
| Drivers | 2x 5.25” polypropylene bass/midrange drivers, 3x 1” soft fabric dome tweeters | 9” micro-ceramic composite (MCC) woofer, 3.5” midrange, 1” aluminum dome tweeter with waveguide (3-way) |
| Enclosure | In-wall | In-wall, passive |
| Mounting Cutout | 288W x 331H mm | 318W x 486H mm |
| Dimensions | 13.9”H x 12.2”W (354 x 311 mm) baffle (95mm mounting depth) | 20.7”H x 13.9”W x 4.1”D (527 x 352 x 103 mm) (95mm mounting depth) |
| Weight | 18.7 lbs (8.5 kg) | 17 lbs (7.7 kg) |
| Sensitivity | 90dB | 85.9dB (measured, Audio Science Review) |
| Impedance | 4 ohms | - |
| Power Handling | 25-400W recommended amplifier power | 10-200W RMS recommended amplifier power |
| Frequency Response | 80Hz-20kHz +/-3dB (manufacturer) | - |
| Bass Extension (-3dB) | 95.2Hz (measured, Erin’s Audio Corner) | 32.2Hz (measured, Audio Science Review) |
| Bass Extension (-10dB) | 68.7Hz (measured, Erin’s Audio Corner) | 22.4Hz (measured, Audio Science Review) |
| Spinorama Preference Score | 2.88 | 3.60 |
| Spinorama Preference Score with Perfect Sub | 6.32 | 5.09 |
| DIY Kit | No | No |
| Warranty | - | 5 years |
Related Speaker Comparisons
More worthwhile head-to-heads for Miller & Kreisel IW150:
- Revel W226Be vs Miller & Kreisel IW150
- JBL Synthesis SCL-6 vs Miller & Kreisel IW150
- JBL Synthesis SCL-3 vs Miller & Kreisel IW150
- JBL Synthesis SCL-7 vs Miller & Kreisel IW150
- JBL Synthesis SCL-4 vs Miller & Kreisel IW150
Prices on this page were last checked September 26, 2026 at 11:14 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
Miller & Kreisel IW150: $4,998 per pair Audiolab (authorized M&K dealer) eBay
Pros: Erin’s Audio Corner’s Klippel measurement shows well controlled directivity (SPDI deviation 2.43dB) and a smooth predicted in-room response, with a preference score of 2.88, or 6.32 with a perfect subwoofer. The unusual layout puts two 5.25” polypropylene woofers beside a column of three 1” soft dome tweeters, a design meant to give even coverage across a room from a single wall opening. It is rated at 90dB sensitivity, and Erin’s measurement computed a real 88.2dB, and it accepts 25-400W of amplifier power. Measured bass extension of 95.2Hz (-3dB).
Cons: Bass is thin: measured -3dB is 95.2Hz and -6dB is 82.0Hz, and Miller & Kreisel rates it only to 80Hz, so a subwoofer is required, and even with a perfect subwoofer the score reaches only 6.32. On-axis smoothness is 0.48 and on-axis deviation averages 0.62dB, so the midrange is rougher than the better in-wall designs. At $2499 each a stereo pair costs twice that. Erin describes it as discontinued from what he can tell, so stock may be limited to remaining inventory.
Full Miller & Kreisel IW150 review and specifications →
| Bass Extension (-10dB) | 68.7Hz (measured, Erin’s Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 95.2Hz (measured, Erin’s Audio Corner) |
| DIY Kit | No |
| Dimensions | 13.9”H x 12.2”W (354 x 311 mm) baffle (95mm mounting depth) |
| Drivers | 2x 5.25” polypropylene bass/midrange drivers, 3x 1” soft fabric dome tweeters |
| Enclosure | In-wall |
| Frequency Response | 80Hz-20kHz +/-3dB (manufacturer) |
| Impedance | 4 ohms |
| Mounting Cutout | 288W x 331H mm |
| Power Handling | 25-400W recommended amplifier power |
| Sensitivity | 90dB |
| Spinorama Preference Score | 2.88 |
| Spinorama Preference Score with Perfect Sub | 6.32 |
| Weight | 18.7 lbs (8.5 kg) |
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
Revel W990: $4,239.90 per pair Crutchfield eBay
Pros: Audio Science Review’s Klippel measurement shows some of the deepest bass of any in-wall speaker, with -3dB at 32.2Hz and -6dB at 27.8Hz, so it can carry music without a subwoofer better than most. Directivity is well controlled (SPDI deviation 1.95dB). It is a three-way with a 9” woofer, a 3.5” midrange and a 1” aluminum dome tweeter, accepts 10-200W of amplifier power, and offers high frequency level, tilt, boundary compensation and listener axis controls to tune it to the room. Measured bass extension of 32.2Hz (-3dB), with a measured sensitivity of 85.9dB.
Cons: Its measured preference score is only 3.6, or 5.09 with a perfect subwoofer, because the midrange is uneven: on-axis deviation is high (0.86 normalized deviation on axis, 0.69 in the listening window) and on-axis smoothness is just 0.34. ASR’s computed sensitivity is about 85.9dB, so it needs more amplifier power than most speakers to play loud. At $2120 each a stereo pair costs twice that, which is a high price for the measured performance.
Full Revel W990 review and specifications →
| Bass Extension (-10dB) | 22.4Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 32.2Hz (measured, Audio Science Review) |
| DIY Kit | No |
| Dimensions | 20.7”H x 13.9”W x 4.1”D (527 x 352 x 103 mm) (95mm mounting depth) |
| Drivers | 9” micro-ceramic composite (MCC) woofer, 3.5” midrange, 1” aluminum dome tweeter with waveguide (3-way) |
| Enclosure | In-wall, passive |
| Mounting Cutout | 318W x 486H mm |
| Power Handling | 10-200W RMS recommended amplifier power |
| Sensitivity | 85.9dB (measured, Audio Science Review) |
| Spinorama Preference Score | 3.60 |
| Spinorama Preference Score with Perfect Sub | 5.09 |
| Warranty | 5 years |
| Weight | 17 lbs (7.7 kg) |
