Klipsch RP-5000F II vs SVS Ultra Evolution Pinnacle

Last updated: October 27, 2026

Short answer: the Klipsch RP-5000F II on value and consistency, the SVS Ultra Evolution Pinnacle for a bigger, time-aligned tower. The RP-5000F II ranks #126 of 228 floorstanding speakers at $859.98 and is the most tonally coherent of the RP II line, though it needs a subwoofer. The Pinnacle costs $2,499 and pairs a 1-inch dome and dual 5.25-inch midranges with four 8-inch bass drivers, but a dip then a peak around 2-3kHz makes vocals shouty.

Klipsch RP-5000F II vs SVS Ultra Evolution Pinnacle

What the SVS Ultra Evolution Pinnacle gets right: A large curved-baffle tower built for time alignment: a 1” dome tweeter flanked by two 5.25” midranges above two 8” mid-bass drivers, plus a matching pair of 8” drivers and dual ports on the back. The catch: Not a fully linear speaker: a dip in the upper midrange followed closely by a peak (roughly 2-3kHz) gives vocals and other midrange content a shouty, forward quality that toe-out alone doesn’t resolve.

Buy the Klipsch RP-5000F II. It is rated higher for sound quality than the SVS Ultra Evolution Pinnacle and costs less, so it is the default pick unless a specific strength of the other one matters more to you.

Looking for alternatives? See the complete Passive Home rankings.

Measured Differences

Prices on this page were last checked November 14, 2026 at 6:17 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.

As an eBay Partner, we may be compensated if you make a purchase.

Specifications Side By Side

Klipsch RP-5000F II SVS Ultra Evolution Pinnacle
Price$859.98 per pair$2,499.00 per pair
Ranked#126 of 228 in Large Size Floorstanding Speakers#151 of 228 in Large Size Floorstanding Speakers
Bass Extension (-10dB)41Hz (measured, Erin’s Audio Corner)about 27.3Hz (measured, Erin’s Audio Corner)
Bass Extension (-3dB)55Hz (measured, Erin’s Audio Corner)41.0Hz (measured, Erin’s Audio Corner via spinorama.org)
Sensitivity90dB (2.83V/1m, measured by Erin’s Audio Corner)88dB
Drivers1” titanium tweeter with Tractrix horn, dual 5.25” cerametallic woofers1” diamond-coated tweeter, dual 5.25” midranges, quad 8” woofers
Weight38.6 lbs (17.5 kg)96.8 lbs (43.9 kg) each
Impedance8 ohms nominal, 3.3 ohms minimum (measured above 80Hz, Erin’s Audio Corner)6 ohms nominal
Frequency Response40Hz - 25kHz (+-3dB, Manufacturer specified)-
Crossover Frequency1900Hz-
Power Handling100W continuous, 400W peak-
Dimensions36.1” x 8.1” x 14.8” (917 x 207 x 375 mm)50.2H x 11.8W x 18.1D in
Woofer Cabinetported, rear-
Spinorama Preference Score5.244.91
Spinorama Preference Score with Perfect Sub7.256.13
DIY KitNoNo
Enclosure-3-way passive, dual rear ports

Where the Ratings Come From

This comparison is generated from the ratings, specifications and measurements on each product’s own page, and it updates when that data changes. How we rank explains how each rating is decided.
