Short answer: the KEF R5 Meta for an easier amplifier load; the Revel F228Be measures flat but dips low in impedance. The F228Be’s spinorama is essentially flat on-axis with very nice directivity, but its minimum impedance dips to 3.4 ohms with a secondary rise around 2kHz. The KEF’s 5” Uni-Q array controls directivity to about +/-50 degrees, though its F3 of 52Hz and F10 of 38Hz call for a subwoofer.
Buy the Revel F228Be new; the KEF R5 Meta is no longer sold new, so it only makes sense as a used find.
Still deciding? The full Passive Home rankings cover every ranked option.
Specifications Side By Side
| KEF R5 Meta | Revel F228Be | |
|---|---|---|
| Price | $3,999.99 per pair Discontinued | $9,000 per pair |
| Ranked | #9 of 74 in Large Size Floorstanding Speakers | #17 of 74 in Large Size Floorstanding Speakers |
| Bass Extension (-10dB) | 38Hz (measured, Erin’s Audio Corner) | 25Hz (measured, Audio Science Review) |
| Bass Extension (-3dB) | 52Hz (measured, Erin’s Audio Corner) | 61Hz (measured, Audio Science Review) |
| Dimensions | 42.2”H x 10.7”W x 13.6”D (1073 x 273 x 346 mm) | 50.9”H x 13.5”W x 17.6”D (1292.9 x 342.9 x 447 mm) |
| Impedance | 4 ohms nominal | 8 ohms |
| Sensitivity | 86dB (measured average, Erin’s Audio Corner) | 89.3dB (300Hz-3kHz @ 2.83V/1m, measured by Audio Science Review; 90dB manufacturer specified) |
| Drivers | 1 in. vented aluminum dome tweeter with MAT, 5 in. aluminum cone midrange, two 5.25 in. hybrid aluminum cone woofers | Dual 8” (200mm) Deep Ceramic Composite aluminum cones, with cast frames woofers, 5-1/4” (130mm) Deep Ceramic Composite aluminum cone, with cast frame midrange, 1” (25mm) Beryllium dome, with acoustic lens waveguide tweeter |
| Weight | 54 lbs (24.5 kg) each | 112.4 lbs (51 kg) each |
| Woofer Cabinet | ported, rear | ported, front |
| Spinorama Preference Score | 6.33 | 6.01 |
| Spinorama Preference Score with Perfect Sub | 8.07 | 7.51 |
| DIY Kit | No | No |
Related Speaker Comparisons
How KEF R5 Meta compares with other leading options:
- KEF Blade Two Meta vs KEF R5 Meta
- MoFi SourcePoint 888 vs KEF R5 Meta
- Revel F328Be vs KEF R5 Meta
- Revel F226Be vs KEF R5 Meta
- KEF R5 Meta vs JBL 4367
Prices on this page were last checked October 2, 2026 at 10:18 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
KEF R5 Meta: $3,999.99 per pair Discontinued eBay
Pros: 12th generation 5” Uni-Q coaxial driver array with Metamaterial Absorption Technology (MAT) delivers remarkably smooth, controlled horizontal (±50°) and vertical directivity with near-identical off-axis tracking. Exceptional frequency response linearity through the midrange and treble that takes extremely well to minor parametric EQ adjustments. Constrained Layer Damping cabinet construction and flexible rear ports minimize enclosure resonances and port turbulence. Deliberately tuned low-frequency roll-off profile permits boundary-adjacent room placement near front walls without boomy acoustic buildup. Measured bass extension of 52Hz (-3dB), with a measured sensitivity of 86dB.
Cons: Low-frequency extension (F3 of 52Hz, F10 of 38Hz) requires pairing with a dedicated subwoofer crossed over at 80Hz for high-output home theater or bass-heavy music performance. High-frequency radiation above 7kHz shows a mild on-axis taper (1-2dB downward slope), performing best when listened to 10-20° off-axis. Moderate sensitivity (~86dB SPL average) requires a clean, robust 4-ohm capable amplifier to drive high dynamic peaks without clipping. Discontinued.
Full KEF R5 Meta review and specifications →
| Bass Extension (-10dB) | 38Hz (measured, Erin’s Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 52Hz (measured, Erin’s Audio Corner) |
| DIY Kit | No |
| Dimensions | 42.2”H x 10.7”W x 13.6”D (1073 x 273 x 346 mm) |
| Drivers | 1 in. vented aluminum dome tweeter with MAT, 5 in. aluminum cone midrange, two 5.25 in. hybrid aluminum cone woofers |
| Impedance | 4 ohms nominal |
| Sensitivity | 86dB (measured average, Erin’s Audio Corner) |
| Spinorama Preference Score | 6.33 |
| Spinorama Preference Score with Perfect Sub | 8.07 |
| Weight | 54 lbs (24.5 kg) each |
| Woofer Cabinet | ported, rear |
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
Revel F228Be: $9,000 per pair Crutchfield eBay
Older model: the Revel F208 (ranked higher, rated 4.5/5).
Pros: CEA2034 spinorama shows an essentially flat on-axis response with very nice directivity. Predicted in-room response is nearly perfect, with a smooth slope down from bass to treble. Horizontal beamwidth of about ±70 degrees is wide and holds up well until narrowing above 8kHz. Vertical directivity offers more degrees of listening-height freedom than a typical bookshelf design, a benefit of this tower’s driver layout. Distortion is extremely low across the full audio range at 86dB SPL/1m and stays comfortable even at 96dB SPL/1m. Near-field measurements of the individual drivers show nice, well-integrated crossover behavior with only low-level resonances. Measured bass extension of 61Hz (-3dB), with a measured sensitivity of 89.3dB.
Cons: Minimum impedance dips to 3.4 ohms with a secondary rise around 2kHz, calling for an amplifier comfortable with a demanding load. Very expensive and very heavy (51 kg each).
Full Revel F228Be review and specifications →
| Bass Extension (-10dB) | 25Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 61Hz (measured, Audio Science Review) |
| DIY Kit | No |
| Dimensions | 50.9”H x 13.5”W x 17.6”D (1292.9 x 342.9 x 447 mm) |
| Drivers | Dual 8” (200mm) Deep Ceramic Composite aluminum cones, with cast frames woofers, 5-1/4” (130mm) Deep Ceramic Composite aluminum cone, with cast frame midrange, 1” (25mm) Beryllium dome, with acoustic lens waveguide tweeter |
| Impedance | 8 ohms |
| Sensitivity | 89.3dB (300Hz-3kHz @ 2.83V/1m, measured by Audio Science Review; 90dB manufacturer specified) |
| Spinorama Preference Score | 6.01 |
| Spinorama Preference Score with Perfect Sub | 7.51 |
| Weight | 112.4 lbs (51 kg) each |
| Woofer Cabinet | ported, front |
