Short answer: both are discontinued, so this only matters if you are buying used. Used, the JBL Studio 630 is the better pick: it ranks #79 of 134 bookshelf speakers by sound quality (rated 3.6/5), against #98 (rated 3.3/5) for the Revel Performa M22. If you want one new, the Ascend Acoustics CMT-340 SE2 ranks #23 at $798.
Buy the JBL Studio 630 only if you find one used in good condition; both are discontinued, and it is the better rated of the two. For a new speaker, start with the Ascend Acoustics CMT-340 SE2 instead.
Still deciding? The full Passive Home rankings cover every ranked option.
Specifications Side By Side
| JBL Studio 630 | Revel Performa M22 | |
|---|---|---|
| Price | $699 per pair Discontinued | $600 per pair used (about), Discontinued |
| Ranked | #79 of 134 in Large Size Bookshelf Speakers | #98 of 134 in Large Size Bookshelf Speakers |
| Drivers | 6.5” PolyPlas cone woofer, 1” compression driver (2414H-1) with waveguide | 25mm tweeter + 200mm woofer |
| Dimensions | 14-13/16”H x 9”W x 11-5/16”D | 14.5”H x 8.6”W x 11.9”D (368.3 x 219.1 x 301.6 mm) |
| Weight | 19.8 lbs (9 kg) each | 41.7 lbs (18.9 kg) |
| Impedance | 6 ohms nominal, 4.7 ohms minimum (measured, Erin’s Audio Corner) | 4 ohms |
| Sensitivity | 83.2dB (measured, Erin’s Audio Corner; 85dB manufacturer specified) | 85dB |
| Frequency Response | 45Hz - 40,000Hz (manufacturer specified) | - |
| Bass Extension (-3dB) | 54.2Hz (measured, Erin’s Audio Corner) | 46.9Hz (measured, Audio Science Review) |
| Bass Extension (-10dB) | 37.0Hz (measured, Erin’s Audio Corner) | 37.1Hz (derived, log-interpolated between spinorama.org -9dB/-12dB points) |
| Power Handling | up to 150W | - |
| Spinorama Preference Score | 3.67 | 5.31 |
| Spinorama Preference Score with Perfect Sub | 5.68 | 7.26 |
| DIY Kit | No | No |
| Woofer Cabinet | - | ported, rear |
Related Speaker Comparisons
How JBL Studio 630 compares with other leading options:
- JBL Studio 630 vs AsciLab C6B
- JBL Studio 630 vs KEF R3 Meta
- JBL Studio 630 vs KEF Q Concerto Meta
- AsciLab F6B vs JBL Studio 630
- JBL Studio 630 vs MoFi SourcePoint 8
Prices on this page were last checked October 3, 2026 at 10:26 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
JBL Studio 630: $699 per pair Discontinued eBay
Pros: Excellent directivity linearity: harmonics of the same instrument stay collocated in the soundstage instead of drifting between positions, giving precise, stable imaging that holds up well into higher frequencies where many speakers start to beam and narrow. Good compression behavior: mid-bass stays taut and controlled from low to high volume without the sound falling apart or distorting as you turn it up. A pleasant, controlled mid-bass bump in the 60-100 Hz range adds punch to kick drums without bleeding into an uncontrolled boom on bass guitar. Horizontal radiation holds steady off-axis (about ±60°), so toe-in isn’t fussy. Compared directly to its predecessor, the JBL Studio 530, the reviewer would pick the 630 (smoother trend line through the upper mids and treble, and likely more dynamic headroom) as long as you’re willing to EQ. Measured bass extension of 54.2Hz (-3dB), with a measured sensitivity of 83.2dB.
Cons: Noticeable mid-range dip/scoop relative to the higher frequencies: not dramatic, but audibly “missing” something by the second or third track. Some tracks read as forward or aggressive around 2 kHz, like the upper frequencies are jumping out at you rather than sitting in stage depth. Needs EQ to bring the mid-range back up to be fully recommendable; without EQ available, the reviewer says he’d look at a different speaker entirely. Measured sensitivity (about 83.2dB) runs noticeably below the 85dB manufacturer spec, likely a byproduct of the mid-range dip skewing the average downward. Discontinued and no longer sold new.
Full JBL Studio 630 review and specifications →
| Bass Extension (-10dB) | 37.0Hz (measured, Erin’s Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 54.2Hz (measured, Erin’s Audio Corner) |
| DIY Kit | No |
| Dimensions | 14-13/16”H x 9”W x 11-5/16”D |
| Drivers | 6.5” PolyPlas cone woofer, 1” compression driver (2414H-1) with waveguide |
| Frequency Response | 45Hz - 40,000Hz (manufacturer specified) |
| Impedance | 6 ohms nominal, 4.7 ohms minimum (measured, Erin’s Audio Corner) |
| Power Handling | up to 150W |
| Sensitivity | 83.2dB (measured, Erin’s Audio Corner; 85dB manufacturer specified) |
| Spinorama Preference Score | 3.67 |
| Spinorama Preference Score with Perfect Sub | 5.68 |
| Weight | 19.8 lbs (9 kg) each |
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
- JBL Studio 630 vs Behringer B2030P
- JBL Studio 630 vs Dynaudio Emit 20
- JBL Studio 630 vs Klipsch RP-600M II
- JBL Studio 630 vs Infinity IL10
- JBL Studio 630 vs Dynaudio Special Forty
- JBL Studio 630 vs ELAC Debut 2.0 B6.2
- JBL Studio 630 vs SVS Prime Bookshelf
- JBL Studio 630 vs Infinity Reference R162
- See all 35 comparisons
Revel Performa M22: $600 per pair used (about) Discontinued eBay
Pros: Very flat frequency response from 200Hz to 10kHz. Distortion is well controlled through most of the range, with only a modest crossover-region bump around 2-4kHz. Measured bass extension of 46.9Hz (-3dB).
Cons: 3dB bass boost around 100Hz. On-axis response also droops below 150Hz and peaks above 4kHz, which the reviewer thought may sound a bit bright/light. Distortion rises substantially below 100Hz when driven hard. Discontinued.
Full Revel Performa M22 review and specifications →
| Bass Extension (-10dB) | 37.1Hz (derived, log-interpolated between spinorama.org -9dB/-12dB points) |
|---|---|
| Bass Extension (-3dB) | 46.9Hz (measured, Audio Science Review) |
| DIY Kit | No |
| Dimensions | 14.5”H x 8.6”W x 11.9”D (368.3 x 219.1 x 301.6 mm) |
| Drivers | 25mm tweeter + 200mm woofer |
| Impedance | 4 ohms |
| Sensitivity | 85dB |
| Spinorama Preference Score | 5.31 |
| Spinorama Preference Score with Perfect Sub | 7.26 |
| Weight | 41.7 lbs (18.9 kg) |
| Woofer Cabinet | ported, rear |
