Short answer: it depends on what you want from the top end. The Infinity Reference 253 has smooth, controlled horizontal beamwidth of about ±60 degrees, but its treble above 4kHz is too hot with a dip around 2kHz and bass shelved down. The JBL Studio 590 reaches pretty deep bass, yet it shows a 3dB peak at 1.7kHz and about a 4dB peak from 8k to 13k, so it will sound bright up top.
Buy the Infinity Reference 253 only if you find one used in good condition; both are discontinued, and it is the better rated of the two. For a new speaker, start with the Revel Concerta2 F35 instead.
Looking for alternatives? See the complete Passive Home rankings.
Specifications Side By Side
| Infinity Reference 253 | JBL Studio 590 | |
|---|---|---|
| Price | $400 per pair used, Discontinued | $2,000 per pair Discontinued |
| Ranked | #60 of 74 in Large Size Floorstanding Speakers | #69 of 74 in Large Size Floorstanding Speakers |
| Bass Extension (-10dB) | 38Hz (measured, Audio Science Review) | 32Hz (measured, Audio Science Review) |
| Bass Extension (-3dB) | 78Hz (measured, Audio Science Review) | 48Hz (measured, Audio Science Review) |
| Dimensions | 40.3”H x 6.8”W x 12.4”D (1023.6 x 172.7 x 315 mm) | 49.7”H x 12.7”W x 16.3”D (1263.0 x 322.0 x 413.0 mm) |
| Impedance | 6 ohms | 6 ohms nominal (5 ohms measured minimum, Audio Science Review) |
| Drivers | Dual 5.25” (130mm) CMMD™ woofers, 5.25” (130mm) flat-piston CMMD™ midrange, 1” (25mm) CMMD™ tweeter | 2x 8” (200mm) PolyPlas cone woofers, 1x 1” (25mm) Teonex dome tweeter on Bi-Radial horn (2.5-way) |
| Sensitivity | 86.9dB (measured by Audio Science Review; 88dB manufacturer specified) | 90.3dB (2.83V/1m, measured by Audio Science Review) |
| Weight | 39.2 lbs (17.8 kg) each | 107.8 lbs (48.9 kg) |
| Woofer Cabinet | ported, rear | ported, rear |
| Spinorama Preference Score | 5.43 (spinorama.org) | 4.49 |
| Spinorama Preference Score with Perfect Sub | 7.31 (spinorama.org) | 6.22 |
| DIY Kit | No | No |
Related Speaker Comparisons
More worthwhile head-to-heads for Infinity Reference 253:
- Revel F226Be vs Infinity Reference 253
- KEF Reference 203 vs Infinity Reference 253
- JBL HDI-3800 vs Infinity Reference 253
- Focal Chora 816 vs Infinity Reference 253
- Revel F208 vs Infinity Reference 253
Prices on this page were last checked October 2, 2026 at 10:18 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
Infinity Reference 253: $400 per pair used Discontinued eBay
Pros: Horizontal beamwidth of about ±60 degrees is fairly smooth and well controlled. Really amazing value for the performance. Measured bass extension of 78Hz (-3dB), with a measured sensitivity of 86.9dB.
Cons: CEA2034 spinorama and predicted in-room response both show elevated treble above 4kHz (“too hot”), a dip around 2kHz, and bass shelved down relative to the midrange. Vertical directivity requires staying at or below the tweeter axis for accurate tonal balance. Distortion at 96dB SPL/1m is broadly elevated above the reviewer’s audibility threshold across much of the midrange. Minimum impedance dips to 4.2 ohms. Discontinued.
Full Infinity Reference 253 review and specifications →
| Bass Extension (-10dB) | 38Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 78Hz (measured, Audio Science Review) |
| DIY Kit | No |
| Dimensions | 40.3”H x 6.8”W x 12.4”D (1023.6 x 172.7 x 315 mm) |
| Drivers | Dual 5.25” (130mm) CMMD™ woofers, 5.25” (130mm) flat-piston CMMD™ midrange, 1” (25mm) CMMD™ tweeter |
| Impedance | 6 ohms |
| Sensitivity | 86.9dB (measured by Audio Science Review; 88dB manufacturer specified) |
| Spinorama Preference Score | 5.43 (spinorama.org) |
| Spinorama Preference Score with Perfect Sub | 7.31 (spinorama.org) |
| Weight | 39.2 lbs (17.8 kg) each |
| Woofer Cabinet | ported, rear |
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
- Infinity Reference 253 vs Magnepan LRS+
- Infinity Reference 253 vs Polk Signature Elite ES60
- Infinity Reference 253 vs JBL Stage 2 280F
- Infinity Reference 253 vs Focal Aria Evo X N°2
- Infinity Reference 253 vs Polk T50
- Infinity Reference 253 vs SVS Ultra Evolution Pinnacle
- Infinity Reference 253 vs Definitive Technology BP-9020
- Infinity Reference 253 vs Sony SS-CS3
- See all 34 comparisons
JBL Studio 590: $2,000 per pair Discontinued eBay
Newer model: the JBL Studio 698, ranked higher, rated 4.3/5.
Pros: Pretty deep bass. CEA2034 spinorama is flat on-axis at a high level, with high sensitivity around 89-90dB. Predicted in-room response is good aside from a dip between 800Hz-1.5kHz. Distortion at 86dB SPL/1m is good outside of the 8.5kHz resonance. Measured bass extension of 48Hz (-3dB), with a measured sensitivity of 90.3dB.
Cons: 3dB peak at 1.7kHz, about a 4dB peak from 8k to 13k, going to be bright up top. Just okay vertical off axis. Really bad resonance at 8.5kHz, which shows up as a sharp distortion spike at both 86dB and 96dB SPL/1m. Cumulative spectral decay (waterfall) reveals many fine resonances across the midrange and treble. At 96dB SPL/1m the midrange and treble get notably messier, with broad distortion elevation from 2-8kHz. Discontinued.
Full JBL Studio 590 review and specifications →
| Bass Extension (-10dB) | 32Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 48Hz (measured, Audio Science Review) |
| DIY Kit | No |
| Dimensions | 49.7”H x 12.7”W x 16.3”D (1263.0 x 322.0 x 413.0 mm) |
| Drivers | 2x 8” (200mm) PolyPlas cone woofers, 1x 1” (25mm) Teonex dome tweeter on Bi-Radial horn (2.5-way) |
| Impedance | 6 ohms nominal (5 ohms measured minimum, Audio Science Review) |
| Sensitivity | 90.3dB (2.83V/1m, measured by Audio Science Review) |
| Spinorama Preference Score | 4.49 |
| Spinorama Preference Score with Perfect Sub | 6.22 |
| Weight | 107.8 lbs (48.9 kg) |
| Woofer Cabinet | ported, rear |
