Short answer: choose between the HK Audio LINEAR 5 112 FA and RCF HD 12-A MK5 for the deployment, not from the automatic ranking alone. Their driver format, power requirements, coverage, bass reach, output capability, and control features determine which is the more practical PA for a particular room or system. The HK Audio LINEAR 5 112 FA has been replaced by the HK Audio Linear 5 MK2 112 FA. If you are buying new, get the HK Audio Linear 5 MK2 112 FA.
The case for the HK Audio LINEAR 5 112 FA. High-quality vendor data yields a 5.07 ideal-subwoofer preference score, while the asymmetric horn can cover wider near-field seating without wasting as much energy upward. The 135dB claimed peak gives it substantial headroom.
The case for the RCF HD 12-A MK5. Medium-quality vendor data indicates useful extension into the low 60Hz region.
Important trade-offs. The 70Hz measured bass extension points toward subwoofer use, and the 52.7 lbs (23.9 kg) cabinet is relatively heavy. This original LINEAR 5 generation lacks the deeper networked DSP and current support advantages of the newer MK2, LINEAR 7 and LINEAR 9 models. The truncated Spinorama measurement cannot produce a preference score, so tonal confidence is lower than for the fully scored leaders. Controls are intentionally simple and omit app control, networking and a multi-input mixer.
Buy the HK Audio LINEAR 5 112 FA when its stated format, coverage, and system features fit the job better.
Buy the RCF HD 12-A MK5 when its stated output, control, and deployment strengths better match the system.
Still deciding? The full PA & Live Sound rankings cover every ranked option.
A powered 12 inch PA speaker with plenty of headroom and an asymmetric horn that spreads sound evenly over nearby seating.
An affordable powered 12 inch PA speaker with loud output, simple controls, and onboard processing that keeps bass tidy.
Prices on this page were last checked October 23, 2026 at 8:27 AM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
Specifications Side By Side
| HK Audio LINEAR 5 112 FA | RCF HD 12-A MK5 | |
|---|---|---|
| Price | $955 Discontinued | $600.00 Discontinued |
| Ranked | #42 of 83 in 12-Inch PA Speakers | #44 of 83 in 12-Inch PA Speakers |
| Passive | No | No |
| Configuration | Active 2-way bass-reflex PA speaker | Active 2-way bass-reflex PA speaker |
| Drivers | 12” woofer, 1” compression driver | 12” woofer, 1.4” compression driver |
| Frequency Response | 64Hz - 18kHz (±3dB, manufacturer specified); 57Hz - 20kHz (-10dB) | 45Hz - 20kHz (manufacturer specified) |
| Dimensions | 26.3”H x 14.6”W x 14.4”D (668 x 370 x 365 mm) | 25.5”H x 15”W x 15”D (647 x 380 x 380 mm) |
| Amplifier Power | 1,000W peak (Class D bi-amped, manufacturer specified) | 1400W peak / 700W RMS (1000W LF + 400W HF peak) |
| Crossover Frequency | 1.65kHz active (24dB/octave) | 1800Hz |
| Cabinet Material | Hybrid birch plywood construction | PP composite |
| Rigging | Three M8 points; DuoTilt 3°/7° pole mount | 2 x M10 inserts; 35mm pole mount |
| Bass Extension (-3dB) | 73Hz (measured, vendor Spinorama data) | 63Hz (measured, vendor Spinorama data) |
| Coverage | 60°-90° asymmetric x 55° | 90° x 60° |
| Maximum SPL | 135dB peak (manufacturer specified) | 130dB peak (manufacturer specified) |
| Inputs | 2 x XLR input, 2 x XLR thru, XLR mix output | XLR/TRS combo input and XLR link |
| DSP | Yes, crossover, EQ and limiting | Yes, FiRPHASE and Bass Motion Control |
| Bluetooth | No | No |
| Weight | 52.7 lbs (23.9 kg) | 40.3 lbs (18.3 kg) |
| Spinorama Preference Score | 2.10 | - |
| Spinorama Preference Score with Perfect Sub | 5.07 | - |
| XLR Input | Yes | Yes |
| RCA Input | No | No |
| TRS Input | No | Yes |
| Optical Input | No | No |
| Coaxial Input | No | No |
| USB Input | No | No |
| HDMI Input | No | No |
| AES Input | No | No |
| Aux Input | No | No |
| Microphone Input | No | No |
| Guitar Input | No | No |
Frequency Response Compared
Both speakers’ spinorama measurements, overlaid. A flatter line is more neutral: peaks sound forward or harsh, dips sound recessed. Each curve is shifted so its average from 300 Hz to 3 kHz sits at 0 dB, so loudness differences between the two are removed and only the shape is compared.
Measurement data: HK Audio LINEAR 5 112 FA (measured by the manufacturer) and RCF HD 12-A MK5 (measured by the manufacturer), via spinorama.org.
