Short answer: choose between the Axiom ED120A and Yamaha DZR12 for the deployment, not from the automatic ranking alone. Their driver format, power requirements, coverage, bass reach, output capability, and control features determine which is the more practical PA for a particular room or system.
The case for the Axiom ED120A. High-quality vendor Spinorama data gives it a 5.73 ideal-subwoofer preference score and 52Hz bass extension, a solid tonal showing for a professional cabinet. CORE DSP, PRONET remote control and an asymmetric rotatable horn add useful installation flexibility.
The case for the Yamaha DZR12. Premium cabinet construction, 139dB claimed output and deep onboard 96kHz DSP suit demanding live work. The local vendor data shows useful 48Hz measured extension, the deepest result among the scored Yamaha models here.
Important trade-offs. The 132dB claimed peak is competitive rather than class-leading, and the asymmetric 60°-to-100° pattern needs more deliberate aiming than a conventional symmetric horn. Availability and service coverage are less broad than the mainstream QSC, JBL, Yamaha and RCF choices. It is heavy at roughly 46.3 lbs (21 kg) and has no Bluetooth audio.
Buy the Axiom ED120A when its stated format, coverage, and system features fit the job better.
Buy the Yamaha DZR12 when its stated output, control, and deployment strengths better match the system.
Still deciding? The full PA & Live Sound rankings cover every ranked option.
Specifications Side By Side
| Axiom ED120A | Yamaha DZR12 | |
|---|---|---|
| Price | $1,790 | $1,409.99 |
| Ranked | #18 of 68 in 12-Inch PA Speakers | #21 of 68 in 12-Inch PA Speakers |
| Configuration | Active 2-way bass-reflex PA speaker | Active 2-way bass-reflex PA speaker |
| Drivers | 12” woofer, 1.4” compression driver | 12” woofer, 2” compression driver |
| Frequency Response | 65Hz - 17kHz (-6dB, manufacturer specified) | 39Hz - 20kHz (manufacturer specified) |
| Dimensions | 24”H x 14.2”W x 12.2”D (610 x 360 x 310 mm) | 25.4”H x 16.1”W x 15.5”D (646 x 410 x 394 mm) |
| Amplifier Power | 1,200W continuous (900W LF + 300W HF Class D, manufacturer specified) | 2000W dynamic / 1100W burst / 950W continuous |
| Cabinet Material | 15mm reinforced phenolic birch plywood | Plywood with polyurea coating |
| Rigging | M10 and M6 fly points; pole-mount socket | M10 points; dual 35mm pole mounts |
| Network Control | PRONET control over EtherCON/CANBUS | - |
| Bass Extension (-3dB) | 60Hz (measured, vendor Spinorama data) | 48Hz (measured, vendor Spinorama data) |
| Coverage | 60°-100° asymmetric x 60° | 90° x 60° |
| Maximum SPL | 132dB peak (manufacturer specified) | 139dB peak (manufacturer specified) |
| Inputs | XLR input and link; EtherCON control network | 2 x XLR/TRS combo |
| DSP | Yes, CORE processing with PRONET control | Yes |
| Bluetooth | No | No |
| Weight | 41.9 lbs (19 kg) | 47.2 lbs (21.4 kg) |
| Spinorama Preference Score | 3.30 | 2.64 |
| Spinorama Preference Score with Perfect Sub | 5.73 | 4.91 |
| XLR Input | Yes | Yes |
| RCA Input | No | No |
| TRS Input | No | Yes |
| Optical Input | No | No |
| Coaxial Input | No | No |
| USB Input | No | No |
| HDMI Input | No | No |
| AES Input | No | No |
| Aux Input | No | No |
| Microphone Input | No | No |
| Guitar Input | No | No |
| Crossover Frequency | - | 1800Hz (FIR-X) |
Related Speaker Comparisons
More worthwhile head-to-heads for Axiom ED120A:
- QSC K12.2 vs Axiom ED120A
- KV2 Audio EX12 vs Axiom ED120A
- JBL PRX912 vs Axiom ED120A
- RCF KX 32-A vs Axiom ED120A
- RCF ART 932-A vs Axiom ED120A
Prices on this page were last checked October 7, 2026 at 9:25 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
Axiom ED120A: $1,790 eBay
Same family: the Axiom ED60P (smaller model, rated 3.3/5), the Axiom ED80P (smaller model, rated 3.4/5) and the Axiom ED150A (larger model, rated 3.8/5).
Pros: High-quality vendor Spinorama data gives it a 5.73 ideal-subwoofer preference score and 52Hz bass extension, a solid tonal showing for a professional cabinet. CORE DSP, PRONET remote control and an asymmetric rotatable horn add useful installation flexibility. Measured bass extension of 60Hz (-3dB).
Cons: The 132dB claimed peak is competitive rather than class-leading, and the asymmetric 60°-to-100° pattern needs more deliberate aiming than a conventional symmetric horn. Availability and service coverage are less broad than the mainstream QSC, JBL, Yamaha and RCF choices.
Full Axiom ED120A review and specifications →
| AES Input | No |
|---|---|
| Amplifier Power | 1,200W continuous (900W LF + 300W HF Class D, manufacturer specified) |
| Aux Input | No |
| Bass Extension (-3dB) | 60Hz (measured, vendor Spinorama data) |
| Bluetooth | No |
| Cabinet Material | 15mm reinforced phenolic birch plywood |
| Coaxial Input | No |
| Configuration | Active 2-way bass-reflex PA speaker |
| Coverage | 60°-100° asymmetric x 60° |
| DSP | Yes, CORE processing with PRONET control |
| Dimensions | 24”H x 14.2”W x 12.2”D (610 x 360 x 310 mm) |
| Drivers | 12” woofer, 1.4” compression driver |
| Frequency Response | 65Hz - 17kHz (-6dB, manufacturer specified) |
| Guitar Input | No |
| HDMI Input | No |
| Inputs | XLR input and link; EtherCON control network |
| Maximum SPL | 132dB peak (manufacturer specified) |
| Microphone Input | No |
| Network Control | PRONET control over EtherCON/CANBUS |
| Optical Input | No |
| RCA Input | No |
| Rigging | M10 and M6 fly points; pole-mount socket |
| Spinorama Preference Score | 3.30 |
| Spinorama Preference Score with Perfect Sub | 5.73 |
| TRS Input | No |
| USB Input | No |
| Weight | 41.9 lbs (19 kg) |
| XLR Input | Yes |
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
Yamaha DZR12: $1,409.99 Amazon B&H Photo Video Guitar Center eBay
Pros: Premium cabinet construction, 139dB claimed output and deep onboard 96kHz DSP suit demanding live work. The local vendor data shows useful 48Hz measured extension, the deepest result among the scored Yamaha models here. Measured bass extension of 48Hz (-3dB).
Cons: Its medium-quality vendor measurement produces only a 4.91 ideal-subwoofer preference score, so the price buys output, processing and build more than neutral tonality. It is heavy at roughly 21kg and has no Bluetooth audio.
Full Yamaha DZR12 review and specifications →
| AES Input | No |
|---|---|
| Amplifier Power | 2000W dynamic / 1100W burst / 950W continuous |
| Aux Input | No |
| Bass Extension (-3dB) | 48Hz (measured, vendor Spinorama data) |
| Bluetooth | No |
| Cabinet Material | Plywood with polyurea coating |
| Coaxial Input | No |
| Configuration | Active 2-way bass-reflex PA speaker |
| Coverage | 90° x 60° |
| Crossover Frequency | 1800Hz (FIR-X) |
| DSP | Yes |
| Dimensions | 25.4”H x 16.1”W x 15.5”D (646 x 410 x 394 mm) |
| Drivers | 12” woofer, 2” compression driver |
| Frequency Response | 39Hz - 20kHz (manufacturer specified) |
| Guitar Input | No |
| HDMI Input | No |
| Inputs | 2 x XLR/TRS combo |
| Maximum SPL | 139dB peak (manufacturer specified) |
| Microphone Input | No |
| Optical Input | No |
| RCA Input | No |
| Rigging | M10 points; dual 35mm pole mounts |
| Spinorama Preference Score | 2.64 |
| Spinorama Preference Score with Perfect Sub | 4.91 |
| TRS Input | Yes |
| USB Input | No |
| Weight | 47.2 lbs (21.4 kg) |
| XLR Input | Yes |
