The Nexus MTM DIY ranks #57 out of 179 total Medium Size Bookshelf Speakers for sound quality. See all Passive Home rankings for every top pick.
Brand: Nexus
Prices on this page were last checked October 20, 2026 at 10:35 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
#57 Nexus MTM DIY: $600 per pair eBay
Pros: Two woofers around the tweeter reach deeper than the Nexus MT DIY: 56.6Hz at -3dB and about 45Hz at -10dB, so it needs less help from a subwoofer. The listening window is fairly even (0.28 deviation), for a preference score of 5.08 that reaches 7.38 with an ideal subwoofer. MTG Designs publishes the crossover and sells a PCB kit, and it is voiced to match the rest of the Nexus family. Measured bass extension of 56.6Hz (-3dB).
Cons: It is a design to build yourself, with no finished retail version. Vertical dispersion is narrow (about 20 degrees either side), as with most MTM layouts, so it sounds best with the tweeter aimed at ear height. The on-axis response is a little less smooth than the Nexus MT DIY, and the measurements are low quality.
| Bass Extension (-10dB) | about 45.1Hz (measured, designer data via spinorama.org) |
|---|---|
| Bass Extension (-3dB) | 56.6Hz (measured, designer data via spinorama.org) |
| DIY Kit | Yes |
| Drivers | 2 woofers and 1 dome tweeter (MTM layout) |
| Spinorama Preference Score | 5.08 |
| Spinorama Preference Score with Perfect Sub | 7.38 |
- Links
- Reviews, Comparisons and Sound Samples
Frequency Response
How the Nexus MTM DIY measures across the audible range. A flatter listening window (the sound arriving straight at you) is more neutral: peaks sound forward or harsh, dips sound recessed. The estimated in-room response adds what a typical room does, and there a gentle, even tilt down toward the treble is ideal. Both curves are shifted so their 300 Hz to 3 kHz average sits at 0 dB.
Measurement data: spinorama.org, measured by an independent reviewer.
EQ for a Neutral Response
No EQ preset: the best simple EQ we can fit to these measurements improves the predicted preference score by less than 0.2. The listening window is already close to flat, and what holds the score back, such as narrow ripple in the response or uneven output off-axis, is not something EQ can fix without making it worse elsewhere.
