The Optimal Audio Cuboid 12 ranks #15 out of 32 total Surface-Mount and Background Music Speakers for sound quality. See all PA & Live Sound rankings for every top pick.
Brand: Optimal Audio
Prices on this page were last checked October 14, 2026 at 2:38 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
#15 Optimal Audio Cuboid 12: $760 each Passive eBay
Pros: A larger member of Optimal Audio’s Cuboid installation range, with a 12-inch woofer that reaches 45.0Hz at -3dB in vendor measurements, deep for an installation box, and a cabinet matching the smaller Optimal Audio Cuboid 5. Measured bass extension of 34.1Hz (-10dB).
Cons: Directivity is uneven (4.60dB variation) and the on-axis response is uneven (0.85 band deviation), so it scores 1.84 on its own and 3.74 with an ideal subwoofer. It is sold through Allen & Heath and Optimal Audio installers with no US retail listing.
| Bass Extension (-10dB) | about 34.1Hz (derived, log-interpolated between spinorama.org -9dB/-12dB points) |
|---|---|
| Bass Extension (-3dB) | 45.0Hz (measured, manufacturer data via spinorama.org) |
| Bluetooth | No |
| DIY Kit | No |
| Drivers | 12” woofer, 2-way |
| Passive | Yes |
| Spinorama Preference Score | 1.84 (spinorama.org) |
| Spinorama Preference Score with Perfect Sub | 3.74 (spinorama.org) |
- Reviews, Comparisons and Sound Samples
Frequency Response
How the Optimal Audio Cuboid 12 measures across the audible range. A flatter listening window (the sound arriving straight at you) is more neutral: peaks sound forward or harsh, dips sound recessed. The estimated in-room response adds what a typical room does, and there a gentle, even tilt down toward the treble is ideal. Both curves are shifted so their 300 Hz to 3 kHz average sits at 0 dB.
Measurement data: spinorama.org, measured by the manufacturer.
EQ for a Neutral Response
Flattens the measured listening window from the Optimal Audio Cuboid 12's own bass extension up to 16 kHz. Set a preamp of -2.9 dB, then add these filters to any parametric equalizer in the signal path: the speaker's app or DSP if it has parametric EQ, a miniDSP, Equalizer APO or Wavelet. Boosts are kept to 3 dB, and EQ cannot fix how evenly the speaker spreads sound off-axis, which is why some speakers gain more than others. Predicted preference score with this EQ: 2.4, up from 1.8 (4.4 with an ideal subwoofer, up from 3.7). Calculated by Speaker Ranking from the spinorama measurements above.
| Filter | Frequency | Gain | Q |
|---|---|---|---|
| High shelf | 8,000 Hz | -0.6 dB | 0.70 |
| Peak | 87 Hz | -6.8 dB | 1.04 |
| Peak | 576 Hz | -3.0 dB | 2.42 |
| Peak | 965 Hz | +2.1 dB | 4.00 |
| Peak | 3,074 Hz | +2.8 dB | 2.28 |
