The JBL CV5012 ranks #49 out of 66 total 12-Inch PA Speakers for sound quality. See all PA & Live Sound rankings for every top pick.
Brand: JBL
Prices on this page were last checked October 5, 2026 at 10:21 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
#49 JBL CV5012 Passive eBay
Pros: The flattest on-axis response of the JBL CV models (0.31dB average deviation in vendor measurements), with bass to about 56Hz at -10dB. A 138dB peak and 98dB sensitivity give big output, and the IP55 birch cabinet suits outdoor venues. Measured bass extension of 92.5Hz (-3dB).
Cons: Preference scores of 1.46 standalone and 4.71 with an ideal subwoofer are modest, because the narrow 60° x 40° pattern makes the off-axis and in-room balance less even. It is passive and weighs 25kg.
How it compares: Just above it: Electro-Voice MFX-12MC. Just below it: Bose AMM112.
| AES Input | No |
|---|---|
| Amplifier Power | Passive speaker; requires external amplification |
| Aux Input | No |
| Bass Extension (-10dB) | about 56.3Hz (measured, vendor Spinorama data) |
| Bass Extension (-3dB) | 92.5Hz (measured, vendor Spinorama data) |
| Bluetooth | No |
| Coaxial Input | No |
| Configuration | Passive 2-way PA speaker, IP55 weather rated |
| Coverage | 60° x 40° |
| DSP | No (passive) |
| Dimensions | 24.8”H x 15.5”W x 16.9”D (630 x 394 x 429 mm) |
| Drivers | 12” woofer with 3” voice coil, JBL 2432H-1 compression driver |
| Frequency Response | 80Hz - 20kHz (±3dB, manufacturer specified) |
| Guitar Input | No |
| HDMI Input | No |
| Impedance | 8 ohms |
| Maximum SPL | 138dB peak / 126dB continuous (manufacturer specified) |
| Microphone Input | No |
| Optical Input | No |
| Power Handling | 600W continuous / 2,400W peak |
| RCA Input | No |
| Sensitivity | 98dB |
| Spinorama Preference Score | 1.46 |
| Spinorama Preference Score with Perfect Sub | 4.71 |
| TRS Input | No |
| USB Input | No |
| Weight | 55.1 lbs (25 kg) |
| XLR Input | No |
