The Coda Audio TiRAY ranks #14 out of 33 total Column and Line Array PA Speakers for sound quality. See all PA & Live Sound rankings for every top pick.
Brand: Coda Audio
Prices on this page were last checked October 14, 2026 at 2:38 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
#14 Coda Audio TiRAY Passive eBay
Pros: A small 9.9kg line array box whose planar wave high-frequency driver gives clean treble, and in vendor data it reaches 45Hz at -3dB, unusually deep for two 5-inch woofers. Scores are 2.88 on its own and 4.89 with an ideal subwoofer, ahead of most line array elements measured. Measured bass extension of 45Hz (-3dB).
Cons: The on-axis response is uneven (1.86dB average deviation) and the predicted in-room response very rough (0.16 smoothness) for a single box. It needs Coda’s processing and is sold through dealers with no published price.
| AES Input | No |
|---|---|
| Amplifier Power | Passive speaker; requires external amplification |
| Aux Input | No |
| Bass Extension (-10dB) | about 39.6Hz (measured, vendor Spinorama data) |
| Bass Extension (-3dB) | 45Hz (measured, vendor Spinorama data) |
| Bluetooth | No |
| Coaxial Input | No |
| Configuration | Passive 2-way compact line array element |
| Coverage | 100° horizontal, 0° to 12° vertical splay |
| DSP | No (passive) |
| Dimensions | 6.1”H x 15.9”W x 10”D (155 x 404 x 253 mm) |
| Drivers | 2 x 5” woofers, 5” planar wave driver |
| Frequency Response | 70Hz - 20kHz (-6dB, manufacturer specified) |
| Guitar Input | No |
| HDMI Input | No |
| Impedance | 8 ohms |
| Maximum SPL | 139dB peak HF, 124dB peak LF per box (manufacturer specified) |
| Microphone Input | No |
| Optical Input | No |
| Passive | Yes |
| Power Handling | 300W AES, 1,200W peak |
| RCA Input | No |
| Rigging | Integrated 3-point rigging, up to 24 boxes |
| Spinorama Preference Score | 2.88 |
| Spinorama Preference Score with Perfect Sub | 4.89 |
| TRS Input | No |
| USB Input | No |
| Weight | 21.8 lbs (9.9 kg) |
| XLR Input | No |
