The Coda Audio CoRay4 is rated 3/5 for sound quality, #26 of 33 Column and Line Array PA Speakers. See all PA & Live Sound rankings for every top pick.
Prices on this page were last checked November 7, 2026 at 7:34 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
Brand: Coda Audio
#26 Coda Audio CoRay4: $2,380 Passive eBay
Pros: A touring and installation column with planar wave drivers and very high peak output, and columns link into longer arrays for big venues. Two 4-inch planar wave drivers above four 5-inch woofers give 97dB sensitivity and a very high 144dB peak, with 120°, 60° or asymmetric 90° horizontal coverage and an asymmetric 12° vertical pattern. Bass reaches 82.5Hz at -3dB, and columns can be linked into a longer array for touring or installation. Measured bass extension of 82.5Hz (-3dB).
Cons: High-quality manufacturer measurements give a low 1.96 standalone preference score and 5.04 with an ideal subwoofer, with a 0.619 listening-window deviation, so tonal balance is uneven. It will not work without a Coda Audio system controller, weighs 15.7kg and is sold only through pro dealers with no published price.
| AES Input | No |
|---|---|
| Amplifier Power | Passive speaker; requires a Coda Audio LINUS amplifier/controller |
| Aux Input | No |
| Bass Extension (-10dB) | about 71.6Hz (measured, vendor Spinorama data) |
| Bass Extension (-3dB) | 82.5Hz (measured, vendor Spinorama data) |
| Bluetooth | No |
| Coaxial Input | No |
| Configuration | Passive 2-way line source column (requires Coda controller) |
| Coverage | 120°, 60° or 90° asymmetric horizontal x 12° vertical |
| DSP | No (passive) |
| Dimensions | 29.8”H x 6”W x 8.4”D (758 x 152 x 214 mm) |
| Drivers | 2x 4” neodymium planar wave drivers, 4x 5” woofers |
| Frequency Response | 80Hz - 20kHz (-6dB, manufacturer specified) |
| Guitar Input | No |
| HDMI Input | No |
| Impedance | 4 ohms |
| Maximum SPL | 144dB peak (manufacturer specified) |
| Microphone Input | No |
| Optical Input | No |
| Passive | Yes |
| Power Handling | 700W AES / 2,800W peak |
| RCA Input | No |
| Rigging | CODA mobile suspension and flange adapter; optional CF4 flying frame |
| Sensitivity | 97dB |
| Spinorama Preference Score | 1.96 |
| Spinorama Preference Score with Perfect Sub | 5.04 |
| TRS Input | No |
| USB Input | No |
| Weight | 34.6 lbs (15.7 kg) |
| XLR Input | No |
