The Alcons Audio LR7 with LR7B ranks #20 out of 33 total Column and Line Array PA Speakers for sound quality. See all PA & Live Sound rankings for every top pick.
Brand: Alcons Audio
Prices on this page were last checked October 14, 2026 at 2:38 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
#20 Alcons Audio LR7 with LR7B Passive eBay
Pros: Measured as a system with its flown 12-inch bass module, it reaches 41Hz at -3dB and about 37Hz at -10dB in vendor data, and the pro-ribbon tweeter gives low treble distortion. The tiny 8kg LR7 box suits theaters and houses of worship where a line array must stay discreet. Measured bass extension of 41.2Hz (-3dB).
Cons: Directivity is uneven (4.09dB variation in the directivity index) and the predicted in-room response is rough (0.42 smoothness), giving scores of 2.47 on its own and 4.31 with an ideal subwoofer. It needs Alcons Sentinel amplified controllers and is sold through dealers with no published price.
| Released | 2009 (17 years ago) |
|---|---|
| AES Input | No |
| Amplifier Power | Passive speaker; requires external amplification |
| Aux Input | No |
| Bass Extension (-10dB) | about 37.2Hz (measured, vendor Spinorama data) |
| Bass Extension (-3dB) | 41.2Hz (measured, vendor Spinorama data) |
| Bluetooth | No |
| Coaxial Input | No |
| Configuration | Passive 2-way pro-ribbon line array element with flown LR7B 12” bass module |
| Coverage | 120° x 15° per box (90° version available) |
| DSP | No (passive) |
| Dimensions | 6.8”H x 14.1”W x 10.7”D (173 x 359 x 273 mm) (LR7); 411H x 359W x 564D mm (LR7B) |
| Drivers | 6.5” woofer, RBN401 4” pro-ribbon (LR7); 12” band-pass subwoofer (LR7B) |
| Frequency Response | 46Hz - 20kHz with LR7B (manufacturer specified) |
| Guitar Input | No |
| HDMI Input | No |
| Impedance | 16 ohms (LR7), 8 ohms (LR7B) |
| Maximum SPL | 129dB peak with Sentinel10 (LR7), 129dB peak (LR7B) (manufacturer specified) |
| Microphone Input | No |
| Optical Input | No |
| Passive | Yes |
| Power Handling | 800W peak at 16 ohms (LR7); 500W RMS at 8 ohms (LR7B) |
| RCA Input | No |
| Rigging | Androgyn flying system, GRD7 grid |
| Spinorama Preference Score | 2.47 |
| Spinorama Preference Score with Perfect Sub | 4.31 |
| TRS Input | No |
| USB Input | No |
| Weight | 17.6 lbs (8 kg) (LR7), 41.9 lbs (19 kg) (LR7B) |
| XLR Input | No |
