The MOONDROP MAY DSP ranks #340 out of 1118 total In-Ear Headphones for sound quality. See all Headphones rankings for every top pick.
Brand: Moondrop
Prices on this page were last checked October 16, 2026 at 5:46 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
#340 MOONDROP MAY DSP: $64.99 Discontinued eBay
Pros: A broadly balanced tuning with a preference score of 75 against the Harman target.
Cons: Discontinued, so it is mainly found used. Treble about 3 dB below target from 3 to 10 kHz, which can sound dull or veiled next to brighter headphones.
Is the MOONDROP MAY DSP right for you?
Buy it if
- you want the tuning most listeners prefer in blind tests out of the box (Harman score 75).
- your taste runs warm: it scores 87 for that sound.
- you are sensitive to bright or sharp treble (treble sits 3.4 dB below target).
- you want sub-bass rumble that reaches down to 20 Hz.
Skip it if
- you want to buy it new: it is discontinued.
| Back | Closed |
|---|---|
| Connection | USB-C |
| Deviation From Target | 1.72 dB standard deviation |
| Driver Type | Hybrid |
| Drivers | 1 x 10mm dynamic + 1 x 6mm planar |
| Form Factor | In-ear |
| Harman Preference Score | 75 (median of 4 squig.link measurements, calibrated to AutoEQ) |
| Impedance | 30 ohms |
| Sensitivity | 120 dB/Vrms |
| Sub-bass Extension | Within 6 dB of target down to 20 Hz (+0.8 dB at 30 Hz) |
| Tonal Tilt | -0.70 (negative is warmer, positive brighter) |
EQ Presets
Harman target
Set a preamp of -4.9 dB, then add these filters in any parametric equalizer (Wavelet, Equalizer APO, Peace, or a player with parametric EQ). Calculated by Speaker Ranking from the median of 4 squig.link measurements, in the filter layout AutoEQ uses. Predicted Harman match with this EQ: 88 out of 100, up from 75.
| Filter | Frequency | Gain | Q |
|---|---|---|---|
| Low shelf | 105 Hz | -0.7 dB | 0.70 |
| High shelf | 10,000 Hz | -4.6 dB | 0.70 |
| Peak | 1,741 Hz | -1.0 dB | 3.48 |
| Peak | 5,440 Hz | +5.1 dB | 1.37 |
Neutral target
Set a preamp of -4.9 dB, then add these filters in any parametric equalizer (Wavelet, Equalizer APO, Peace, or a player with parametric EQ). Calculated by Speaker Ranking from the median of 4 squig.link measurements, in the filter layout AutoEQ uses. Predicted Neutral match with this EQ: 90 out of 100, up from 36.
| Filter | Frequency | Gain | Q |
|---|---|---|---|
| Low shelf | 105 Hz | -9.2 dB | 0.70 |
| High shelf | 10,000 Hz | -4.6 dB | 0.70 |
| Peak | 23 Hz | -1.4 dB | 1.77 |
| Peak | 1,742 Hz | -1.0 dB | 3.50 |
| Peak | 5,439 Hz | +5.1 dB | 1.37 |
Studio flat target
Set a preamp of -4.2 dB, then add these filters in any parametric equalizer (Wavelet, Equalizer APO, Peace, or a player with parametric EQ). Calculated by Speaker Ranking from the median of 4 squig.link measurements, in the filter layout AutoEQ uses. Predicted Studio flat match with this EQ: 89 out of 100, up from 17.
| Filter | Frequency | Gain | Q |
|---|---|---|---|
| Low shelf | 105 Hz | -11.4 dB | 0.70 |
| High shelf | 10,000 Hz | +1.7 dB | 0.70 |
| Peak | 171 Hz | -2.3 dB | 0.56 |
| Peak | 1,633 Hz | -1.1 dB | 4.03 |
| Peak | 2,926 Hz | +2.0 dB | 4.10 |
| Peak | 5,345 Hz | +3.2 dB | 0.52 |
| Peak | 7,182 Hz | -1.4 dB | 4.61 |
Warm target
Set a preamp of -3.2 dB, then add these filters in any parametric equalizer (Wavelet, Equalizer APO, Peace, or a player with parametric EQ). Calculated by Speaker Ranking from the median of 4 squig.link measurements, in the filter layout AutoEQ uses. Predicted Warm match with this EQ: 94 out of 100, up from 87.
| Filter | Frequency | Gain | Q |
|---|---|---|---|
| Low shelf | 105 Hz | -0.5 dB | 0.70 |
| High shelf | 10,000 Hz | -6.0 dB | 0.70 |
| Peak | 1,893 Hz | -1.4 dB | 2.72 |
| Peak | 6,057 Hz | +3.7 dB | 1.81 |
Bass target
Set a preamp of -4.9 dB, then add these filters in any parametric equalizer (Wavelet, Equalizer APO, Peace, or a player with parametric EQ). Calculated by Speaker Ranking from the median of 4 squig.link measurements, in the filter layout AutoEQ uses. Predicted Bass match with this EQ: 90 out of 100, up from 80.
| Filter | Frequency | Gain | Q |
|---|---|---|---|
| Low shelf | 105 Hz | +3.1 dB | 0.70 |
| High shelf | 10,000 Hz | -4.6 dB | 0.70 |
| Peak | 1,741 Hz | -1.0 dB | 3.48 |
| Peak | 5,441 Hz | +5.1 dB | 1.37 |
Bright target
Set a preamp of -5.9 dB, then add these filters in any parametric equalizer (Wavelet, Equalizer APO, Peace, or a player with parametric EQ). Calculated by Speaker Ranking from the median of 4 squig.link measurements, in the filter layout AutoEQ uses. Predicted Bright match with this EQ: 80 out of 100, up from 24.
| Filter | Frequency | Gain | Q |
|---|---|---|---|
| Low shelf | 105 Hz | -9.3 dB | 0.70 |
| High shelf | 10,000 Hz | -0.9 dB | 0.70 |
| Peak | 23 Hz | -1.4 dB | 1.91 |
| Peak | 1,753 Hz | -1.1 dB | 2.68 |
| Peak | 3,503 Hz | +1.5 dB | 4.11 |
| Peak | 5,345 Hz | +6.0 dB | 1.20 |
| Peak | 6,887 Hz | -2.4 dB | 5.69 |
V-shaped target
Set a preamp of -6.1 dB, then add these filters in any parametric equalizer (Wavelet, Equalizer APO, Peace, or a player with parametric EQ). Calculated by Speaker Ranking from the median of 4 squig.link measurements, in the filter layout AutoEQ uses. Predicted V-shaped match with this EQ: 78 out of 100, up from 66.
| Filter | Frequency | Gain | Q |
|---|---|---|---|
| Low shelf | 105 Hz | +3.7 dB | 0.70 |
| High shelf | 10,000 Hz | +0.4 dB | 0.70 |
| Peak | 4,638 Hz | +6.0 dB | 1.20 |
- Reviews, Comparisons and Sound Samples
Frequency Response
How the MOONDROP MAY DSP measures across the audible range, against the Harman in-ear target that most listeners prefer in blind tests. Where the line sits above the target that range sounds louder (more bass, brighter treble), below it quieter. The curve is the median of 4 independent measurements, so one odd sample or rig cannot skew it, and both lines are shifted so their 500 Hz to 2 kHz average sits at 0 dB.
Measurement data: median of 4 measurements from the squig.link databases of arn, ianfann, theaudiostore and treblewellxtended. Thanks to each of them for publishing their work.
