Short answer: it is a tradeoff between a clean cabinet and a flatter response. The Infinity Reference R162 has good directivity and early reflections that need little room treatment, but elevated output above 3kHz adds brightness, with a resonance around 700Hz. The Yamaha NS-800A’s cabinet is exceptionally well built, yet its wide 2kHz-10kHz scoop is the more audible flaw, and it costs $4,999.90 against $500.
Buy the Yamaha NS-800A. It is rated higher for sound quality; the Infinity Reference R162 is no longer sold new.
Want more options? Browse the full Passive Home rankings.
Specifications Side By Side
| Yamaha NS-800A | Infinity Reference R162 | |
|---|---|---|
| Price | $4,999.90 per pair | $500 per pair Discontinued |
| Ranked | #58 of 134 in Large Size Bookshelf Speakers | #67 of 134 in Large Size Bookshelf Speakers |
| Bass Extension (-10dB) | 35Hz (measured, Erin’s Audio Corner) | 41.9Hz (derived, log-interpolated between spinorama.org -9dB/-12dB points) |
| Bass Extension (-3dB) | 68Hz (measured, Erin’s Audio Corner) | 67.4Hz (measured, Audio Science Review) |
| Impedance | 6 ohms nominal, 4.3 ohms minimum (measured above 80Hz, Erin’s Audio Corner) | 8 ohms nominal |
| Sensitivity | 84.9dB (measured average 300Hz-3kHz @ 2.83V/1m, Erin’s Audio Corner; 86.5dB manufacturer specified) | 87dB (2.83V/1m, measured, Audio Science Review) |
| Drivers | 1.25” dome tweeter, 6.5” mid-woofer | 1” CMMD tweeter with waveguide, 6.5” CMMD woofer |
| Weight | 28.7 lbs (13.0 kg) each | 17.6 lbs (8 kg) each |
| Dimensions | 16.5”H x 9.1”W x 14.1”D (419.1 x 231.8 x 358.8 mm) | 15.5”H x 7.9”W x 11.2”D (394 x 200 x 285 mm) |
| Woofer Cabinet | Bass reflex | ported |
| Crossover Frequency | 2600Hz | - |
| Power Handling | 40W nominal, 120W max | - |
| Spinorama Preference Score | 4.66 | 5.07 (spinorama.org) |
| Spinorama Preference Score with Perfect Sub | 6.43 | 7.26 (spinorama.org) |
| DIY Kit | No | No |
| Frequency Response | - | 49Hz - 22kHz (Manufacturer specified) |
Related Speaker Comparisons
More top alternatives to Yamaha NS-800A:
- AsciLab C6B vs Yamaha NS-800A
- KEF R3 Meta vs Yamaha NS-800A
- KEF Q Concerto Meta vs Yamaha NS-800A
- KEF R3 vs Yamaha NS-800A
- Wharfedale Super Linton vs Yamaha NS-800A
Prices on this page were last checked October 2, 2026 at 10:18 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
Yamaha NS-800A: $4,999.90 per pair The Music Room eBay
Pros: Exceptionally well-built cabinet with no internal resonance issues at all: confirmed clean in both burst decay and impedance measurements. Good, wide directivity (~75 degrees horizontal) that stays consistent enough to EQ successfully. Distortion is low, staying under 3% at 96dB, and dynamic range holds up well until right near its 102dB limit. A shallower, higher-frequency bass rolloff profile (F3 68Hz, F10 35Hz) means it can be placed closer to the wall (about a foot) without turning boomy, actually gaining bass presence rather than losing it. Measured bass extension of 68Hz (-3dB), with a measured sensitivity of 84.9dB.
Cons: A wide, roughly 2kHz-10kHz scoop in the upper-midrange/lower-treble gives it a laidback, soft, low-attack character: notably worse than the reviewer’s Audio First Fidelia reference in an A/B comparison. On top of that, treble breaks up badly above 10kHz, swinging up as much as 8dB: a significant, named flaw. Sounds inconsistently voiced as a result (bright on some material like cymbals and shakers, dull/laidback on vocals and instrument attack) until corrected with real parametric EQ (the reviewer needed a +2dB boost around 4.5kHz at Q0.5 plus taming the treble spike to bring it to life) combined with near-wall placement and 30-degree toe-out. Without that combination, it’s a tough sale for a $5000 bookshelf speaker.
Full Yamaha NS-800A review and specifications →
| Bass Extension (-10dB) | 35Hz (measured, Erin’s Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 68Hz (measured, Erin’s Audio Corner) |
| Crossover Frequency | 2600Hz |
| DIY Kit | No |
| Dimensions | 16.5”H x 9.1”W x 14.1”D (419.1 x 231.8 x 358.8 mm) |
| Drivers | 1.25” dome tweeter, 6.5” mid-woofer |
| Impedance | 6 ohms nominal, 4.3 ohms minimum (measured above 80Hz, Erin’s Audio Corner) |
| Power Handling | 40W nominal, 120W max |
| Sensitivity | 84.9dB (measured average 300Hz-3kHz @ 2.83V/1m, Erin’s Audio Corner; 86.5dB manufacturer specified) |
| Spinorama Preference Score | 4.66 |
| Spinorama Preference Score with Perfect Sub | 6.43 |
| Weight | 28.7 lbs (13.0 kg) each |
| Woofer Cabinet | Bass reflex |
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
- Yamaha NS-800A vs Definitive Technology Demand D11
- Yamaha NS-800A vs ELAC DBR62
- Yamaha NS-800A vs Technics SB-C700
- Yamaha NS-800A vs Dynaudio Contour 20i
- Yamaha NS-800A vs ELAC Uni-Fi Reference UBR62
- Yamaha NS-800A vs SVS Ultra Bookshelf
- Yamaha NS-800A vs Revel Concerta2 M16
- Yamaha NS-800A vs JBL HDI-1600
- See all 22 comparisons
Infinity Reference R162: $500 per pair Discontinued eBay
Pros: CEA2034 spinorama shows good directivity with wide, consistent horizontal and vertical response, and blended early reflections that need little room treatment. 1” CMMD waveguide tweeter and 6.5” CMMD woofer, 85.5dB sensitivity. Measured bass extension of 67.4Hz (-3dB), with a measured sensitivity of 87dB.
Cons: Elevated output above 3kHz adds brightness, with a resonance around 700Hz and some distortion near the crossover point. EQ or a simple inline tweeter resistor can tame the treble; the reviewer still called it a very enjoyable system for the price. Discontinued.
Full Infinity Reference R162 review and specifications →
| Bass Extension (-10dB) | 41.9Hz (derived, log-interpolated between spinorama.org -9dB/-12dB points) |
|---|---|
| Bass Extension (-3dB) | 67.4Hz (measured, Audio Science Review) |
| DIY Kit | No |
| Dimensions | 15.5”H x 7.9”W x 11.2”D (394 x 200 x 285 mm) |
| Drivers | 1” CMMD tweeter with waveguide, 6.5” CMMD woofer |
| Frequency Response | 49Hz - 22kHz (Manufacturer specified) |
| Impedance | 8 ohms nominal |
| Sensitivity | 87dB (2.83V/1m, measured, Audio Science Review) |
| Spinorama Preference Score | 5.07 (spinorama.org) |
| Spinorama Preference Score with Perfect Sub | 7.26 (spinorama.org) |
| Weight | 17.6 lbs (8 kg) each |
| Woofer Cabinet | ported |
