Short answer: the Revel W553L. Both are rated 4.5/5 for sound quality (#2 and #1 of 28 in-wall speakers), and the Revel W553L costs $1,089.90 against $3,773.90 for the KEF Ci3160RLM-THX, so with nothing between them on sound quality, price settles it.
Why pick the Revel W553L: An in-wall speaker with excellent, accurate sound for the money, a swiveling tweeter, and mounting for left, right or center. The tradeoff: At $545 each a stereo pair costs twice that, and a separate amplifier is required.
What the KEF Ci3160RLM-THX does well: An excellent in-wall speaker, with highly accurate, flat sound, very consistent dispersion and an aimable driver module for off-center installs. Watch for: At $1887 each, a stereo pair costs twice that, among the most expensive options in this category.
Buy the Revel W553L. Both are rated the same for sound quality, and it costs $2,684 less than the KEF Ci3160RLM-THX.
Want more options? Browse the full Passive Home rankings.
Prices on this page were last checked November 7, 2026 at 7:34 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
Specifications Side By Side
| Revel W553L | KEF Ci3160RLM-THX | |
|---|---|---|
| Price | $1,089.90 per pair | $3,773.90 per pair |
| Ranked | #2 of 28 in In-Wall & In-Ceiling Speakers | #1 of 28 in In-Wall & In-Ceiling Speakers |
| Drivers | 2x 5.25” micro-ceramic composite (MCC) woofers, 1” swiveling aluminum dome tweeter with waveguide | 2x 6.5” LF woofers, 6.5” Uni-Q coaxial midrange, 1” vented aluminum dome tweeter with MAT (rotatable/tiltable module) |
| Enclosure | In-wall, LCR (vertical or horizontal mounting) | Open-backed, in-wall |
| Mounting Cutout | 163W x 359H mm | 660mm (H) x 209mm (W) |
| Dimensions | 15.1”H x 7.4”W (384 x 188 mm) (74mm mounting depth) | 26.8” x 9.1” x 4.2” (680 x 230 x 105.7 mm) |
| Weight | 7.7 lbs (3.5 kg) | 26.5 lbs (12 kg) |
| Sensitivity | 90dB | 89dB |
| Power Handling | 10-150W recommended amplifier power | 50-350W recommended amplifier power |
| Warranty | Lifetime | - |
| Bass Extension (-3dB) | 64.5Hz (measured, Erin’s Audio Corner) | 58.6Hz (measured, spinorama.org ASR data) |
| Bass Extension (-10dB) | 39.3Hz (measured, Erin’s Audio Corner) | 36Hz (measured, spinorama.org ASR data) |
| Spinorama Preference Score | 4.84 | 5.32 |
| Spinorama Preference Score with Perfect Sub | 7.50 | 7.83 |
| DIY Kit | No | No |
| Impedance | - | 4 ohms |
| Frequency Response | - | 43Hz-28kHz +/-6dB (manufacturer, open-backed) |
| Certification | - | THX Ultra2 |
