Short answer: the Bose DesignMax DM5SE, though neither ranks well in its class. Both are rated 2.2/5 for sound quality (#25 and #26 of 26 surface-mount and background music speakers), and the Bose DesignMax DM5SE costs $897.05 against $936 for the Bose DesignMax DM6SE, and with sound quality even, the cheaper one is the better buy. Both are rated below 3.0/5 among the 26 surface-mount and background music speakers, and the JBL Control 24CT, ranked #1 at $350, is a better place to start if sound quality matters.
What the Bose DesignMax DM5SE does well: An IP55 surface-mount installation speaker from Bose Professional with a 5.25” coaxial driver. The tradeoff: The response is uneven and bass is limited, for a low preference score.
What the Bose DesignMax DM6SE does well: An IP55 surface-mount installation speaker from Bose Professional with a 6.5” coaxial driver. Watch for: The on-axis response is very uneven (3.11 average deviation).
Buy the Bose DesignMax DM5SE. Both are rated the same for sound quality, and it costs $38.95 less than the Bose DesignMax DM6SE.
Want more options? Browse the full PA & Live Sound rankings.
Specifications Side By Side
| Bose DesignMax DM5SE | Bose DesignMax DM6SE | |
|---|---|---|
| Price | $897.05 per pair Passive | $936.00 per pair Passive |
| Ranked | #25 of 26 in Surface-Mount and Background Music Speakers | #26 of 26 in Surface-Mount and Background Music Speakers |
| Rigging | QuickHold U-bracket; M8 inserts for pan and tilt bracket | QuickHold U-bracket; 2 x M8 bracket inserts; M8 safety tether insert |
| Weight | 9.7 lbs (4.38 kg) | 13.1 lbs (5.93 kg) |
| Maximum SPL | 111dB peak (manufacturer specified) | 107dB peak (manufacturer specified) |
| Passive | Yes | Yes |
| Bluetooth | No | No |
| Drivers | 5.25” coaxial driver | 6.5” coaxial driver |
| IP Rating | IP55 | IP55 |
| Bass Extension (-3dB) | 77.5Hz (measured, manufacturer data via spinorama.org) | 71.0Hz (measured, manufacturer data via spinorama.org) |
| Bass Extension (-10dB) | about 68.3Hz (measured, manufacturer data via spinorama.org) | about 62.0Hz (measured, manufacturer data via spinorama.org) |
| Spinorama Preference Score | -0.41 | -0.04 |
| Spinorama Preference Score with Perfect Sub | 2.61 | 2.87 |
| DIY Kit | No | No |
Frequency Response Compared
Both speakers’ spinorama measurements, overlaid. A flatter line is more neutral: peaks sound forward or harsh, dips sound recessed. Each curve is shifted so its average from 300 Hz to 3 kHz sits at 0 dB, so loudness differences between the two are removed and only the shape is compared.
Measurement data: Bose DesignMax DM5SE (measured by the manufacturer) and Bose DesignMax DM6SE (measured by the manufacturer), via spinorama.org.
Related Speaker Comparisons
More top alternatives to Bose DesignMax DM5SE:
- JBL AC25 vs Bose DesignMax DM5SE
- Bose DesignMax DM8SE vs Bose DesignMax DM5SE
- Bose DesignMax DM8SE vs Bose DesignMax DM6SE
- JBL AC25 vs Bose DesignMax DM6SE
- Optimal Audio Cuboid 5 vs Optimal Audio Cuboid 3
Prices on this page were last checked October 11, 2026 at 4:59 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
Bose DesignMax DM5SE: $897.05 per pair Passive Amazon eBay
Same family: the Bose DesignMax DM6SE (larger model, ranked lower, rated 2.2/5) and the Bose DesignMax DM8SE (larger model, ranked higher, estimated 2.4/5). See every Bose DesignMax generation.
Pros: An IP55 surface-mount installation speaker from Bose Professional with a 5.25” coaxial driver. Bose’s measurements show a preference score of -0.41 that reaches 2.61 with an ideal subwoofer, with 1.03 listening window deviation.
Cons: The response is uneven and bass is limited, for a low preference score. The data comes from Bose. Bass reaches 77.5Hz (-3dB) and about 68Hz (-10dB).
Full Bose DesignMax DM5SE review and specifications →
| Released | Oct 2020 (6 years ago) |
|---|---|
| Bass Extension (-10dB) | about 68.3Hz (measured, manufacturer data via spinorama.org) |
| Bass Extension (-3dB) | 77.5Hz (measured, manufacturer data via spinorama.org) |
| Bluetooth | No |
| DIY Kit | No |
| Drivers | 5.25” coaxial driver |
| IP Rating | IP55 |
| Maximum SPL | 111dB peak (manufacturer specified) |
| Passive | Yes |
| Rigging | QuickHold U-bracket; M8 inserts for pan and tilt bracket |
| Spinorama Preference Score | -0.41 |
| Spinorama Preference Score with Perfect Sub | 2.61 |
| Weight | 9.7 lbs (4.38 kg) |
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
Bose DesignMax DM6SE: $936.00 per pair Passive Amazon eBay
Same family: the Bose DesignMax DM5SE (smaller model, ranked higher, rated 2.2/5) and the Bose DesignMax DM8SE (larger model, ranked higher, estimated 2.4/5). See every Bose DesignMax generation.
Pros: An IP55 surface-mount installation speaker from Bose Professional with a 6.5” coaxial driver. Bose’s measurements show a preference score of -0.04 that reaches 2.87 with an ideal subwoofer, with 1.00 listening window deviation.
Cons: The on-axis response is very uneven (3.11 average deviation). The data comes from Bose. Bass reaches 71.0Hz (-3dB) and about 62Hz (-10dB).
Full Bose DesignMax DM6SE review and specifications →
| Released | Oct 2020 (6 years ago) |
|---|---|
| Bass Extension (-10dB) | about 62.0Hz (measured, manufacturer data via spinorama.org) |
| Bass Extension (-3dB) | 71.0Hz (measured, manufacturer data via spinorama.org) |
| Bluetooth | No |
| DIY Kit | No |
| Drivers | 6.5” coaxial driver |
| IP Rating | IP55 |
| Maximum SPL | 107dB peak (manufacturer specified) |
| Passive | Yes |
| Rigging | QuickHold U-bracket; 2 x M8 bracket inserts; M8 safety tether insert |
| Spinorama Preference Score | -0.04 |
| Spinorama Preference Score with Perfect Sub | 2.87 |
| Weight | 13.1 lbs (5.93 kg) |
