Short answer: the Revel Concerta2 M16 on price, the JBL HDI-1600 on measurements. The Revel costs $600, $1,380 less and its CEA2034 spinorama is essentially flat from 200Hz to 10kHz with some bass boost around 100Hz, but harmonic distortion shows a peak around 80Hz and a sharp spike around 350Hz, and the woofer gets unhappy before the tweeter handoff. The JBL ranks #45 of 134 with a very flat spinorama, but dips above 10kHz on axis.
Buy the JBL HDI-1600 only if you find one used in good condition; both are discontinued, and it is the better rated of the two. For a new speaker, start with the AsciLab C6B instead.
Looking for alternatives? See the complete Passive Home rankings.
Specifications Side By Side
| JBL HDI-1600 | Revel Concerta2 M16 | |
|---|---|---|
| Price | $1980 per pair Discontinued | $600 per pair used (about), Discontinued |
| Ranked | #45 of 134 in Large Size Bookshelf Speakers | #51 of 134 in Large Size Bookshelf Speakers |
| Bass Extension (-3dB) | 55.7Hz (measured, Audio Science Review) | 60.1Hz (measured, Audio Science Review) |
| Bass Extension (-10dB) | 40Hz (derived, log-interpolated between spinorama.org -9dB/-12dB points) | 41.6Hz (measured, Audio Science Review) |
| Impedance | 4 ohms nominal (measured, Audio Science Review) | 6 ohms |
| Sensitivity | 85dB (2.83V/1m, measured, Audio Science Review) | 86dB |
| Drivers | 1” tweeter + 6.5” woofer | 25mm tweeter + 165mm woofer |
| Weight | 53.4 lbs (24.2 kg) | 32 lbs (14.5 kg) |
| Dimensions | 14.6”H x 9.1”W x 11.4”D (370.0 x 230.0 x 288.9 mm) | 14.8”H x 8.6”W x 10.8”D (374.7 x 218.4 x 273.3 mm) |
| Woofer Cabinet | ported, rear | ported, rear |
| Spinorama Preference Score | 5.37 (spinorama.org) | 5.06 |
| Spinorama Preference Score with Perfect Sub | 7.32 (spinorama.org) | 7.28 |
| DIY Kit | No | No |
Related Speaker Comparisons
More top alternatives to JBL HDI-1600:
- KEF R3 Meta vs JBL HDI-1600
- KEF Q Concerto Meta vs JBL HDI-1600
- MoFi SourcePoint 8 vs JBL HDI-1600
- Dynaudio Heritage Special vs JBL HDI-1600
- Wharfedale Linton 85 vs JBL HDI-1600
Prices on this page were last checked October 2, 2026 at 10:18 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
JBL HDI-1600: $1980 per pair Discontinued Crutchfield eBay
Pros: CEA2034 spinorama is very flat in the critical mid-to-upper frequencies, with a slight bass boost that should have a good subjective effect and very smooth early-window directivity. Predicted in-room response in a simulated average listening room closely tracks the reviewer’s own preferred target curve. Measured bass extension of 55.7Hz (-3dB), with a measured sensitivity of 85dB.
Cons: A dip appears above 10kHz on-axis. Cumulative spectral decay (waterfall) shows some messiness around the crossover along with a 700Hz resonance. Harmonic distortion rises to nearly 2% right at the 1.9kHz crossover point at 96dB SPL/1m. Discontinued.
Full JBL HDI-1600 review and specifications →
| Bass Extension (-10dB) | 40Hz (derived, log-interpolated between spinorama.org -9dB/-12dB points) |
|---|---|
| Bass Extension (-3dB) | 55.7Hz (measured, Audio Science Review) |
| DIY Kit | No |
| Dimensions | 14.6”H x 9.1”W x 11.4”D (370.0 x 230.0 x 288.9 mm) |
| Drivers | 1” tweeter + 6.5” woofer |
| Impedance | 4 ohms nominal (measured, Audio Science Review) |
| Sensitivity | 85dB (2.83V/1m, measured, Audio Science Review) |
| Spinorama Preference Score | 5.37 (spinorama.org) |
| Spinorama Preference Score with Perfect Sub | 7.32 (spinorama.org) |
| Weight | 53.4 lbs (24.2 kg) |
| Woofer Cabinet | ported, rear |
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
- JBL HDI-1600 vs Aalto Speakers Aalto 3 Passive
- JBL HDI-1600 vs Arendal 1723 Bookshelf S THX
- JBL HDI-1600 vs ELAC Debut 3.0 DB63
- JBL HDI-1600 vs Emotiva Airmotiv XB2
- JBL HDI-1600 vs ELAC Uni-Fi Reference UBR62
- JBL HDI-1600 vs ELAC VELA BS 403
- JBL HDI-1600 vs Revel M126Be
- JBL HDI-1600 vs Ascend Acoustics Sierra-LX
- See all 29 comparisons
Revel Concerta2 M16: $600 per pair used (about) Discontinued eBay
Pros: CEA2034 spinorama shows an on-axis response that’s essentially flat from 200Hz to 10kHz, with some bass boost around 100Hz. Predicted in-room response is very nice, with just extra bass and a bit of roll-off above 20kHz: the reviewer calls it “nice!” Distortion is well controlled through most of the range at both test levels. Measured bass extension of 60.1Hz (-3dB).
Cons: Harmonic distortion shows a notable peak around 80Hz and a sharp spike around 350Hz, plus the woofer appears to get a bit unhappy right before handing off to the tweeter. Cumulative spectral decay (waterfall) shows some lingering resonances in the 300Hz-1kHz region. The reviewer cautions not to over-cover the cabinet/grille area with thin fabric, as it can audibly affect the top-end response. Discontinued.
Full Revel Concerta2 M16 review and specifications →
| Bass Extension (-10dB) | 41.6Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 60.1Hz (measured, Audio Science Review) |
| DIY Kit | No |
| Dimensions | 14.8”H x 8.6”W x 10.8”D (374.7 x 218.4 x 273.3 mm) |
| Drivers | 25mm tweeter + 165mm woofer |
| Impedance | 6 ohms |
| Sensitivity | 86dB |
| Spinorama Preference Score | 5.06 |
| Spinorama Preference Score with Perfect Sub | 7.28 |
| Weight | 32 lbs (14.5 kg) |
| Woofer Cabinet | ported, rear |
