The Tannoy Revolution XT 6 ranks #119 out of 134 total Large Size Bookshelf Speakers for sound quality. See all Passive Home rankings for every top pick.
Brand: Tannoy
Prices on this page were last checked October 1, 2026 at 6:23 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
#119 Tannoy Revolution XT 6: $1,100 per pair Discontinued eBay
Pros: Horizontal directivity is very good outside of a narrow glitch around 2.5kHz, meaning the coaxial design’s off-axis sound closely tracks on-axis within a +/-50 degree toe-in window. Vertical response is notably better than a typical non-coaxial 2-way thanks to the concentric driver, and the downward-firing, base-integrated port is a distinctive, functional piece of industrial design. Measured bass extension of 71.8Hz (-3dB), with a measured sensitivity of 86.5dB.
Cons: CEA2034 spinorama shows significant on-axis dips and rising amplitude above 3kHz, and distortion measurements are the headline problem: 4-5% distortion at 96dB SPL in the most sensitive part of the audible band, far higher than the Revel M106 comparison unit at the same level. Careful multi-notch EQ improved things but never fully resolved it. The reviewer’s conclusion: “I can’t recommend the Tannoy XT 6”. The coaxial design’s distortion should have been addressed by the designer, not patched after the fact with EQ. Discontinued.
How it compares: Just above it: Triad In-Room Gold LCR - $5500 more, 2.4Hz higher bass extension (-3dB). Just below it: Cerwin Vega LA165 - $834 cheaper, 0.3Hz lower bass extension (-3dB).
| Bass Extension (-10dB) | 46.8Hz (derived, log-interpolated between spinorama.org -9dB/-12dB points) |
|---|---|
| Bass Extension (-3dB) | 71.8Hz (measured, Audio Science Review) |
| DIY Kit | No |
| Dimensions | 15.8H x 8.7W x 11.9D in |
| Drivers | 6” dual-concentric multifiber-cone woofer with coaxial 1” PEI dome tweeter |
| Impedance | 8 ohms nominal |
| Power Handling | 25-120W recommended, 240W peak |
| Sensitivity | 86.5dB (2.83V/1m, measured, Audio Science Review) |
| Spinorama Preference Score | 2.15 |
| Spinorama Preference Score with Perfect Sub | 4.67 |
| Weight | 16.5 lbs (7.5 kg) each |
| Woofer Cabinet | ported, bottom-firing |
