Revel Performa M22 vs JBL XPL-90

Last updated: October 31, 2026

Short answer: it depends on whether the top end bothers you. The JBL XPL-90 is nearly ruler-flat on-axis up to 1kHz with even horizontal directivity until the tweeter beams above 10kHz, but crossover region peaking around 3kHz and treble peaking above 10kHz color the top end, and poor vertical directivity means the tweeter needs to be at ear level. The Revel Performa M22 is very flat from 200Hz to 10kHz with a 3dB bass boost around 100Hz.

Revel Performa M22 vs JBL XPL-90

Buy the Revel Performa M22 only if you find one used in good condition; both are discontinued, and it is the better rated of the two. For a new speaker, buy the Revel M126Be, which replaces the Revel Performa M22.

Looking for alternatives? See the complete Passive Home rankings.

Measured Differences

Prices on this page were last checked November 14, 2026 at 6:17 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.

As an eBay Partner, we may be compensated if you make a purchase.

Specifications Side By Side

Revel Performa M22 JBL XPL-90
Price$600 per pair used (about), Discontinued$1,298 per pair used (vintage, late 1980s), Discontinued
Ranked#165 of 222 in Large Size Bookshelf Speakers#181 of 222 in Large Size Bookshelf Speakers
Bass Extension (-10dB)37.1Hz (derived, log-interpolated between spinorama.org -9dB/-12dB points)48.7Hz (measured, Audio Science Review)
Bass Extension (-3dB)46.9Hz (measured, Audio Science Review)77.6Hz (measured, Audio Science Review)
Impedance4 ohms6 ohms
Sensitivity85dB85dB (2.83V/1m, measured, Audio Science Review)
Drivers25mm tweeter + 200mm woofer6.5” bass/mid driver, 1” titanium dome tweeter
Weight41.7 lbs (18.9 kg)20.1 lbs (9.1 kg) each
Dimensions14.5”H x 8.6”W x 11.9”D (368.3 x 219.1 x 301.6 mm)15.5”H x 9.5”W x 9.8”D (394 x 241 x 248 mm)
Woofer Cabinetported, rear-
Spinorama Preference Score5.313.7 (spinorama.org)
Spinorama Preference Score with Perfect Sub7.266.31 (spinorama.org)
DIY KitNoNo
Power Handling-100W nominal, 400W max

Where the Ratings Come From

This comparison is generated from the ratings, specifications and measurements on each product’s own page, and it updates when that data changes. How we rank explains how each rating is decided.
