ELAC IW-S10EQ in-wall Specifications and Review

The ELAC IW-S10EQ in-wall ranks #2 out of 3 total Small Passive Home Subwoofers (Under 30 lbs) for sound quality. See Top Recommended Speakers By Attribute for all the top speaker suggestions.

#2 ELAC IW-S10EQ in-wall

  • CEA-2010-A Average (40-80Hz): 103.9 dB
  • Cabinet Color: black
  • Country: Germany
  • Dimensions: 12.2”H x 12.2”W x 4.23”D (309.9 x 309.9 x 107.4 mm)
  • Discontinued: Yes
  • Driver(s): (1) 10 inch
  • Enclosure: in-wall
  • Measurement Source: Brent Butterworth
  • Output SPL at 15 Hz: 86.0 dB
  • Output SPL at 20 Hz: 90.2 dB
  • Output SPL at 25 Hz: 97.3 dB
  • Output SPL at 31.5 Hz: 97.9 dB
  • Output SPL at 40 Hz: 100.3 dB
  • Output SPL at 50 Hz: 103.0 dB
  • Output SPL at 63 Hz: 104.5 dB
  • Output SPL at 80 Hz: 107.9 dB
  • Passive: Yes
  • Warranty: 3/1
  • Weight: 14.24lbs / 6.5kg
